• NDP-15BAU Yamada NDP-15 Series AODD Diaphragm Pump 851949-U

Image shown may not be actual product

Yamada

NDP-15BAU

0 reviews

Yamada NDP-15BAU NDP-15 Series Air Operated Double Diaphragm Pump, Model 851949-U. Aluminum Body with Ball Valve, Ultimate PTFE/EPDM Diaphragm & Ball Materials, PTFE O-Rings. 1/2" FNPT Inlet & Outlet, Repair Kit K15-MU Available.

$1,280.00

Item: NDP-15BAU | Model #: 851949-U

NDP-15BAU

Yamada NDP-15BAU NDP-15 Series Air Operated Double Diaphragm Pump, Model 851949-U. Aluminum Body with Ball Valve, Ultimate PTFE/EPDM Diaphragm & Ball Materials, PTFE O-Rings. 1/2" FNPT Inlet & Outlet, Repair Kit K15-MU Available.

Air Inlet1/4" FNPT
Air Supply Pressure20 - 100 PSI (1.4 - 7 kfg/cm)
DiaphragmUltimate PTFE/EPDM
Discharge NPT (Inches)1/2" FNPT
Discharge Volume Per Cycle0.0338 gallons (128 cc)
Fluid Port1/2"
MaterialAluminum
Maximum Flow (GPM)13.5
Max Suction Lift5'
Model Number851949-U
MotorAluminum
Solids (Inches)1/32" (1mm)
Suction NPT (Inches)1/2" FNPT
TypeBall Valve
Valve BallsUltimate PTFE/EPDM
Valve / Seat / O-RingPTFE

NDP-15 Series Information

Features & Benefits
Port Dimensions
Intake & discharge connection:
Polypropylene (PPG) ■ 1/2" Female NPT
Kynar® (PVDF)◆ 1/2" Female NPT
Groundable Acetal ◆ 1/2" Female NPT
Aluminum (ADC-12) ▲ 1/2" Female NPT
Stainless Steel (316) ▲ 1/2" Female NPT
Air inlet (includes ball valve): 1/4" Female NPT
Air exhaust (internal silencer): 3/8" Female NPT

■ Polypropylene pumps may be fitted with ball or flat check valves. Ball-type check valves are recommended for flooded suction applications. Flat-type check valves are recommended for suction lift applications.
◆ Kynar® and Groundable Acetal pumps are fitted with flat check valves only.
▲ Aluminum and Stainless Steel pumps are fitted with ball check valves only.

Maximum Liquid Temperature*
Diaphragm Material Temperature
Buna N 180°F (82°C)
Neoprene 180°F (82°C)
Santoprene® (TPO) 180°F (82°C)
PTFE 212°F (100°C)
Hytrel® (TPEE) 248°F (120°C)
Viton® fluoroelastomer 248°F (120°C)

*The maximum liquid temperature for metal and Kynar® fitted pumps is determined by the elastomer (diaphragm material). Polypropylene and Groundable Acetal pumps have a maximum liquid temperature of 180°F (82°C) regardless of diaphragm material.

Categories

0 Reviews

Add a Review

You need to sign in to add a review.

TypeTitleLink

Yamada Pumps NDP-15 Pump Manual

View

Yamada Pumps NDP-15 Pump PPG CAD Drawing

View

Yamada Pumps NDP-15 Pump SS CAD Drawing

View

Yamada Pumps NDP-15 Pump Specifications

View

Yamada Pumps NDP-15 Pump Aluminum CAD Drawing

View

NDP-15BAU Ultimate Diaphragm Series Repair Parts

View

Repair Parts for NDP-15BAU

Productqty.shippingprice
683171

683171

Ships in 1-2 Weeks $13.00
631329

631329

Ships in 1-2 Weeks $5.00
681300

681300

Ships in 1-2 Weeks $5.00
628012

628012

Ships in 1-2 Weeks $5.00
643025

643025

Ships in 1-2 Weeks $6.00
771523

771523

Ships in 1-2 Weeks $46.00
771524

771524

Ships in 1-2 Weeks $14.00
711227

711227

Ships in 1-2 Weeks $28.00
711226

711226

Ships in 1-2 Weeks $155.00
802708

802708

Ships in 1-2 Weeks $147.00
686826

686826

Ships in $21.00
621102

621102

Ships in 1-2 Weeks $5.00
717185

717185

Ships in $40.00
643130

643130

Ships in 1-2 Weeks $11.00
02-1160

02-1160

Ships in Call for pricing
640144

640144

Ships in 1-2 Weeks $5.00
640020

640020

Ships in 1-2 Weeks $5.00
684284

684284

Ships in 1-2 Weeks $8.00
771337

771337

Ships in 1-2 Weeks $9.00
021161 Call for Shipping
771336

771336

Ships in 1-2 Weeks $21.00
643005

643005

Ships in 1-2 Weeks $6.00
681849

681849

Ships in 1-2 Weeks $12.00
684916

684916

Ships in 1-2 Weeks $5.00
780029

780029

Ships in 1-2 Weeks $379.00
771347

771347

Ships in 1-2 Weeks $12.00
780030

780030

Ships in 1-2 Weeks $194.00
771342

771342

Ships in 1-2 Weeks $6.00
20109-YAM

20109-YAM

Ships in $8.00
771483

771483

Ships in 1-2 Weeks $6.00
804249

804249

Ships in 1-2 Weeks $82.00
683123

683123

Ships in 1-2 Weeks $6.00
802835

802835

Ships in 1-2 Weeks $289.00
771484

771484

Ships in 1-2 Weeks $9.00
771695

771695

Ships in 1-2 Weeks $60.00
640022

640022

Ships in 1-2 Weeks $5.00
771350

771350

Ships in 1-2 Weeks $12.00
640002

640002

Ships in 1-2 Weeks $5.00
771589

771589

Ships in 1-2 Weeks $18.00
771465

771465

Ships in 1-2 Weeks $13.00
832141

832141

Ships in 1-2 Weeks $28.00
710577

710577

Ships in 1-2 Weeks $6.00
632752

632752

Ships in 1-2 Weeks $5.00
682727

682727

Ships in 1-2 Weeks $5.00
771123

771123

Ships in 1-2 Weeks $6.00
631328

631328

Ships in 1-2 Weeks $5.00
681855

681855

Ships in 1-2 Weeks $5.00
628010

628010

Ships in 1-2 Weeks $5.00
K15-MU

K15-MU

Ships in $426.00
K15-AM

K15-AM

Ships in 1-2 Weeks $168.00
