MTH Pumps

140 / 280 / 180 / 280 Regenerative Turbine Pumps

MTH 140, 240, 180 & 280 Series regenerative turbine pumps represent the most economical, high performance alternative flow (to 60 GPM) applications involving moderate to high pressures (heads to 800 feet). By combining years of regenerative turbine pump designs with precision computer controlled manufacturing, the 140 / 280 / 180 / 280 line of pumps deliver high efficiency pumping operation, even at low NPSH. High quality parts and an easily serviceable design provide low maintenance and long life.

Impeller Blades

After the most favorable impeller profile has been determined for a particular water passageway cross-section, MTH calculates the number of blades needed to maximize the performance of that pump. Current blade design in 140 • 240 • 180 • 280 Series pumps increases both efficiency and design pressure without the manufacturing difficulties associated with producing contoured blade impellers. State-of-the-art computer controlled machines simplify manufacturing of the various MTH impellers utilized in the 140 • 240 • 180 • 280 Series. The result is a high performance pump providing efficiency characteristics exceeding those of more expensive units.

Limitations

• Discharge Pressure 400 PSI
• Seal Pressure* 200 PSI
• Suction Pressure (Min.) 26” Hg. Vac.
• Speed 1750 RPM
• Horsepower 15 HP

Temperature

• Standard Construction -20° F
• Ceramic Seal Seat - Water +230° F
• Ni-Resist Seal Seat - Water +230° F
• Silicon Carbide Seal Seat & External Seal Flush +250° F

150 / 250 / 160 / 260 / 170 / 270 Flexible Turbine Pumps

MTH 150, 250, 160, 260, 170, 270 Flexible coupled regenerative turbine pumps are the most economical high performance pumps for low flow. 150 Gallons Per Minute (GPM) low flow applications involving moderate to high pressures of heads to 1150 feet. MTH combined many years of  turbine pump designs with ultra precision PC controlled manufacturing. The MTH 150 / 250 / 160 /  260 / 170 / 270 pump models deliver ultimate pumping operation efficiency, especially at low NPSH. Top quality parts and a proven easily serviceable design leads to low maintenance and long life.

Limitation

• Discharge Pressure 500 PSI
• Seal Pressure* 200 PSI
• Suction Pressure (Min.) 26” Hg Vac.
• Speed 1750 RPM
• Horsepower 60 HP

Temperature

• Standard Construction -20°F
• Ceramic Seal Seat - Water 230°F
• Silicon Carbide Seal Seat & External Seal Flush 250°F

C41 • C51 • C61 Series Close Coupled Centrifugal Pumps

C Series Close Coupled Economical Pump Series ranges from 5gpm to 100 GPM for applications at 140 head of feet. MTH's C 41, C51 and C61 model pumps over superior efficiency and low NSPH situations. If you are looking for a low cost centrifugal pump option with minimum matenence and opterations costs, give us a call.

Specifications

• Horizontal Close Coupled Design
• 105 GPM (Gallons Per Minute) Capacity
• 153 Heads to Feet
• Semi Open Impeller
• Mecahnical Seal Box

D51 / D61 / D71/ D91 Centrifugal Pumps

MTH Close-coupled centrifugal pumps offer economical performance up to 240 gallons per minute (GPM). Perfect for applications requiring heads to 360 feet. MTH combined the latest concepts in pump design with precision manufacturing, the D Series pumps deliver excellent efficiency and low NPSH requirements. Efficient manufacturing processes and highly optimized mechanical designs control costs. Maintenance costs are kept to a minimum by combining a highly serviceable design with quality components to provide a long service life.

Mechanical Seal Type 21 Buna-N seal is rated to 225°F and up to 175 PSI and is used on the D51, D61, D71, and D91 Pump Series. The carbon seal face mates with a ceramic seat providing years of trouble-free service. The seal cooling jacket high temperature version of the D51 unit uses a Type 21 Viton seal that is rated to 400°F with pressures up to 175 PSI. Alternate seals available upon request.

Limitations

• Discharge Pressure 250 PSI
• Suction Pressure (Max) 250 PSI
• Suction Pressure (Min) 26” Hg Vac.
• Speed (Max.) 3600 RPM

Temperature

• Standard Construction -20° F
• Ceramic Seal Seat - Water +225° F
• Graph. Imp. Silicon Carbide
• Seal Seat & Seal Flush +250° F
• Cooling Jacketed 500° F
• Horsepower 56J Frame 3 HP JM Frame 100 HP

DC10 Washdown 12 Volt Centrifugal Pumps

Impeller Design

MTH DC10 Series semi-open impellers allow the pump to pass small solids and fibrous material while close running tolerances maintain high efficiency and performance. Impellers are pre-trimmed to be non-overloading to the pump and motor size indicated.

Mechanical Seal Box

DC10's large seal chamber provides a wide fluid passage area for maximum cooling of the seal faces and allows debris and gases to be flushed away.

Adjustable Casing

DC Series pump casings are axially adjustable allowing the use of custom impellers for OEM applications and to allow restoration of performance by closing up the internal clearances that develop over the course of a unit’s extended service life.

Design Features

• 100% Solid Stainless Steel Construction
• Capacities to 25 GPM
• Heads to 92 Feet (40 PSI)
• Temperatures from -20° to 250°F
• End Suction and Top, Bottom, or Side Discharge
• 12VDC 1HP TENV Motor
• Weighs 48 LBS

Specifications

• Stainless Steel Casing
• Stainless Steel Motor Bracket
• Cast Stainless Steel Impeller
• Adjustable Impeller to Casing Clearance
• “O” Ring Style Elastomer
• Long Lasting Dry Run Mechanical Seal
• Totally Enclosed DC Motor
• Easy Access Brass Terminals

M50 | L50 Regenerative Turbine Pumps

MTH M50 & L50 pump series are vertical, base mount & horizontal pedestal mounted multi-stage regenerative turbine pumps. This series represent the most economical high performance alternative for low flow (2 to 38 GPM) applications involving moderate to high pressures (heads to 2300 feet). By combining the latest concepts in hydraulic turbine pump design with precision computer controlled manufacturing, M50 & L50 Series pumps deliver high efficiency operation even at low NPSH. Costs are controlled by efficient manufacturing processes, use of standard motors, and highly optimized pump designs. Maintenance costs are kept to a minimum by combining an easily serviceable design with the use of high quality components to provide long life.

Features

• Mecahnical Seals  - Buna N Seals on bronze fitted pumps. Optional seals available.
• 1,000 PSI (Pounds Per Square Inch) Case Working Pressure - Maximum Case Strength
• Volitile Fluid Handling - Handles vapors up to 20% by volume to minimize vapor lock.
• O-Ring Gaskets - Positive Sealing Assured.
• Motors - 56C Face Standard Motors are used up to 3 HP. 5 HP and above are TEFC on vertical base units.
• Non-Cavitating - MTH's M50 & L50 pumps can be operated under adverse inlet conditions without audible or mesurable cavitation.
• Low NPSH - New inlet design along with the L50 series inducer sytle pumps offer excellent fluid handling with low inlet head conditions.

Motors Horizontal Rigid Base - MTH Pumps

C2 / D3 / C3 / C15 / C30 STYLES

Offering motor options for MTH Pump series:

• P31 Horizontal Close Coupled
• T41 / E41 & T51 / E51 Horizontal Close Coupled (Flexible Coupled & Sealless Canned)
• 140 / 240 / 180 / 280 Series Turboflex Regenerative Turbine Pumps
• X41 Sealless Canned

Single (1PH) and Thre Phase (3PH) Motors in Both ODP - Open Drip Proof and TEFC - Totally Enclosed Fan Cooled Enclosures.

Style and C-Face Motors

• C Style 36 Frame
• C3 Style 56C Face
• C15 Style 556C Face
• D3 Style 556C Dual Face

MTH Pumps is a commercial and industrial pump manufacturer serving a wide variety of markets and industries including boiler feed, condensate return, chillers / temperature controllers, water services, refrigeration, petroleum, as well as many chemical process applications. Our standard product lines include mechanically sealed regenerative turbines for low flow, high pressure, applications (1000PSI & 150GPM) as well as a line of small centrifugals (60PSI & 100GPM). We also have custom engineered products such as sealless canned versions of our turbine product lines as well as a large line of sealless canned centrifugals in ranges up to 300PSI and 2000GPM. In fact, to our knowledge, MTH Pumps has the broadest line of turbine and sealless canned pump products available in the world.

P31 Series Regenerative Turbine Pumps

MTH's P31 compact stainless steel pumps are and excellent option for an econimical and extended service life turbine pump.

Specifications

• 250 Heads to Feet
• Max Operating Temperature up to 250°F
• 5 Gallons Per Minute (GPM) Capacities
• Stainless Steel Material of Construction
• Suction and Discharge at Top
• Casing is Adjustable for Maximum Performance and Service Life
• Integral Relief Valve is Optional

Repair Parts & Rebuild Kits - MTH Pumps

We carry repair parts and rebuild kits for the following MTH Pump series:

• P31 Horizontal Close Coupled
• T41 / E41 & T51 / E51 Horizontal Close Coupled (Flexible Coupled & Sealless Canned)
• 140 / 240 / 180 / 280 Series Turboflex Regenerative Turbine Pumps
• X41 Sealless Canned

MTH Pumps T31 Series close-coupled regenerative turbine pumps represent the most economical, high performance alternative for low flow (1/2 to 10 GPM) applications involving moderate to high pressures (heads to 300 feet). By combining the latest concepts in hydraulic turbine pump design with precision computer controlled manufacturing, the T31 Series pumps deliver high efficiency pumping operation, even at low NPSH. Maintenance costs are kept to a minimum by combining an easily serviceable design with the use of high quality components to provide long life.

MTH E41 / T41 Close-coupled and pedestal mounted regenerative turbine pumps represent the most economical, high perfor-mance alternative for low flow (1/2 to 22 GPM) clean fluid applications involving moderate to high pressures (heads to 600 feet).By combining the latest concepts in hydraulic turbine pump design with precision computer controlled manu-facturing, the E41/T41 Series pumps deliver high efficiency operation even at low NPSH. Costs are controlled by efficient manufacturing processes and highly optimized pump designs. Maintenance costs are kept to a minimum by combining an easily serviceable design with the use of high quality components to provide long life.

MTH T51 / E51 Close-coupled and pedestal mounted regenerative turbine pumps represent the most economical, high performance alternative for low flow (2 to 40 GPM) clean fluid applications involving moderate to high pressures (heads to 700 feet). By combining the latest concepts in regenerative turbine pump design with precision computer controlled manufacturing, the T51 • E51 Series pumps deliver high efficiency operation, even at low NPSH. Costs are controlled by efficient manufacturing processes and highly optimized pump designs. Maintenance costs are kept to a minimum by combining an easily serviceable design with the use of high quality components to provide long life.

X / X41 Sealless Canned Regenerative Turbine Pumps

MTH X41 models are sealless regenerative turbine pumps, known as canned hermetic or zero emission pumps, These turbine pumps are designed to handle applications with hard to seal fluids when leak free performance is required. Mechanical seals simply cannot provide the reliability, protection and performance needed. Water and glycol mixtures and exotic heat transfer fluids present no difficulty for these pumps at fluid temperatures from -40°C up to 130°C. MTH's canned motor design is favorable to magnetic drive couplings because it does not add length to the pumps in tight OEM enclosures. These models also do not suffer from the magnetic de-coupling problems often associated with mag-drive solutions. Three bearings, high strength cast stainless steel components, and a sealless design assure extended trouble free maintenance life span.

X41 Design Benefits & Features

• Extremely Long Service Life
• Leak Free Sealless Design
• Canned Stator Motor
• Capacities to 22 GPM (Gallons Per Minute)
• Heads to 450 Feet
• Low NPSH Requirements
• Temperature Range -40°C to 130°C
• Compact Integrated Design
• Stainless Steel Wetted Parts for Excellent Chemical Compatibility
• Standard NPT Threads with optional SAE, BSP, and ISO Available
• Conduit or Electrical Junction Box
• Variable Frequency Drive / Transducer Package Optional

Low NPSH Requirements
Like its T41 Series mechanically sealed counterpart, the X Series hydraulic passageways are designed to minimize thrust on the selfadjusting impeller to avoid upsetting its hydraulic balance, and to handle low NPSH conditions which can occur in some applications. New to the X Series is the location of the inlet and outlet on the centerline of the impeller to further eliminate the potential of axial imbalance that sometimes occurs during periods of marginal NPSH availability.
