JXHF Series High Temperature / High-Head Corrosion Resistant Dewatering Pumps Information

Features & Benefits

The JXHF Series delivers a unique combination of high-temperature capability, corrosion resistance, and high head performance. This makes it well suited for applications requiring durability under both thermal and chemical stress while maintaining strong hydraulic output.

Seal Minder® monitoring enhances reliability by providing early indication of seal failure, helping reduce downtime and maintenance costs.

Construction and Operational Design

JXHF pumps are constructed entirely from cast 316 stainless steel, ensuring uniform corrosion resistance across all wetted components. The no-weld design enhances structural integrity and minimizes potential points of failure in corrosive environments.

The sealing system includes two mechanical seals along with an independent lip seal, creating multiple protective barriers against fluid intrusion. FKM elastomers are used as standard for compatibility with a wide range of chemicals, with optional materials available for specialized applications.

Each unit is driven by a high-speed 2-pole motor operating at approximately 3450 RPM. Class R insulation allows the motor to withstand elevated temperatures, while embedded thermal sensors provide protection against overheating during operation.

Design Characteristics

Temperature Capability: Designed for operation in liquids up to 200°F (93°C)

High Head Capability: Engineered to deliver head pressures up to approximately 145 ft

Corrosion Resistance: Cast 316 stainless steel construction provides superior protection in aggressive environments

Discharge Configuration: Side discharge design supports guide rail installation and flexible system integration

Seal System: Double mechanical seal with independent lip seal ensures enhanced sealing reliability

Materials of Construction: Fully 316 stainless steel wetted parts and motor housing

Solids Handling: Capable of handling solids up to 3/8 inch

Motor Design: High-speed 2-pole motor (~3450 RPM) with Class R insulation for high-temperature performance

Protection Features: Thermal sensors embedded in motor windings and Seal Minder® moisture detection system

Technical Summary

Power Range: 2 HP to 10 HP

Flow Capacity: Up to ~340+ GPM

Head Range: Up to ~145 feet

Solids Handling: Up to 3/8 inch

Temperature Capability: Up to 200°F (93°C)

Motor Speed: ~3450 RPM

Typical Services & Ideal Applications

The JXHF Series is specifically engineered for high-temperature, high-head applications in corrosive environments. These pumps are commonly used in industrial facilities, chemical processing systems, heated water handling, and demanding dewatering applications where both pressure and temperature resistance are required.

Their ability to combine corrosion resistance, thermal durability, and high-pressure performance makes them an ideal solution for maintaining reliability and uptime in extreme operating conditions.
