62180403

Solids-Handling Submersible Pumps Information

Reliable Wastewater Pumps for Residential, Commercial, and Municipal Applications

The Barmesa Solids-Handling Pump Series was developed to provide dependable performance in applications where liquids contain suspended solids, debris, sludge, or sewage. From small 2-inch residential systems to large municipal pumping stations, this product family offers a wide range of pump sizes and hydraulic configurations to help customers match pump performance to their specific system requirements.

One of the biggest advantages of the series is the variety of available designs. Customers can choose from open-vane, semi-open, closed-vane, and vortex impeller configurations depending on the type of solids being handled and the desired pumping performance. Smaller models provide an economical solution for commercial and light wastewater applications, while larger units are built for continuous-duty municipal and industrial service.

Durability is a major focus throughout the product line. Cast iron housings, stainless steel shafts, oil-filled motors, and corrosion-resistant hardware help these pumps withstand challenging wastewater environments. Many models also feature oil-filled seal chambers and silicon carbide mechanical seals designed to improve reliability and reduce maintenance requirements.

As pump size increases, additional protection features become available, including moisture sensors, temperature sensors, double mechanical seals, and Class F insulated motors. These safeguards help operators identify issues early and protect equipment operating in demanding conditions.

Key Benefits

– Solids handling up to 3 inches

– Available in 2", 3", 4", 6", and 8" discharge sizes

– Horsepower ratings from 0.4 HP to 60 HP

– Open, semi-open, closed, and vortex impeller options

– Heavy-duty cast iron construction

– Stainless steel shafts and hardware

– Oil-filled motors and seal chambers

– Single or double mechanical seal designs

– Available moisture and temperature monitoring

– Residential, commercial, municipal, and industrial coverage

Whether the application involves a small sewage basin, a commercial wastewater system, or a high-capacity municipal lift station, the Barmesa Solids-Handling Series provides the flexibility, durability, and performance needed to keep wastewater systems operating efficiently. With a broad range of pump sizes and hydraulic designs, these pumps offer practical solutions for virtually any solids-handling application.
