NDP-5FAT

Image shown may not be actual product

NDP-5FAT

0 reviews

Yamada America NDP-5FAT NDP-5 Series Air Operated Double Diaphragm Pump, Model Number 851564. Aluminum Body, PTFE Diaphragm, Flat Valve & O-Rings, Ryton Air Motor. 1/4" FNPT Inlet & Outlet, 3.4 GPM Flow Rate.

$730.00

Best Price Guarantee!
146PumpPoints

Ships within 1 business day (in-stock items). Delivery typically 1–5 business days.

Item: NDP-5FAT | Model #: 851564

Repair Parts Exploded View Diagram

Overview
Series Info
Reviews
Literature/Manuals
Repair Parts

NDP-5FAT

Air Exhaust	3/8" Female NPT (includes silencer)
Air Inlet	1/4" Female NPT (includes ball valve)
Air Supply Pressure	20-100 PSI
Connection Type	FNPT
Diaphragm	PTFE
Discharge NPT (Inches)	1/4"
Discharge Volume Per Cycle	0.0078 Gallons
Fluid Port	1/4"
Liquid Temperature	212°F (100°C)
Material	Aluminum
Max Cycles Per Minute	400

Maximum Flow (GPM)	3.4
Max Suction Lift	5'
Model Number	851564
Model Series	NDP-5
Motor	Ryton
Suction NPT (Inches)	1/4"
Valve Balls	PTFE (Flat Valve)
Valve / Seat / O-Ring	PTFE O-Rings
Valve Type	Flat

NDP-5 Series Information

Features & Benefits
Port Dimensions Intake & discharge 1/4" Female NPT Air inlet (incl. ball valve): 1/4" Female NPT Air exhaust (internal silencer): 3/8" Female NPT Maximum Liquid Temperature Fitted with PTFE diaphragm Pump Material Temperature Groundable Acetal 180°F (82°C) Polypropylene (PPG) 180°F (82°C) Aluminum (ADC-12) 212°F (100°C) Kynar® (PVDF) 212°F (100°C) Stainless Steel (316) 212°F (100°C)
Notes
Hytrel®-fitted pumps include Hytrel® check balls & Buna N wetted o‑rings. Santoprene®-fitted pumps include Santoprene® check balls and EPDM wetted o‑rings. K5-PT-2 (replaces K5-PT) starting Serial Number is 228480. K5-PT is still available.

0 Reviews

Add a Review

You need to sign in to add a review.

Type	Title		Link
	Yamada Pumps NDP-5 Pump Manual		View
	Yamada Pumps NDP-5 Pump Specifications		View
	Yamada Pumps NDP-5 Pump PPG CAD Drawing		View
	Yamada Pumps NDP-5 Pump SS CAD Drawing		View
	Yamada Pumps NDP-5 Pump Aluminum CAD Drawing		View
	NDP-5FAT Yamada Pump Repair Parts Exploded View		View
