Image shown may not be actual product

EJ-B09VCBR

0 reviews

Walchem EJ-B09VCBR Economical Chemical Injection Pump, PVC Pump Head & 3/8" OD x 1/4" ID Connections. 0.3 GPH Max Flow, 175 Max PSI, 230 Volts, 50/60 Hz, PTFE + EPDM Diaphragm, CE Valve, FKM Valve Seat, FKM O-Ring, PTFE Gasket.

$445.00

Best Price Guarantee!
89PumpPoints

Item: EJ-B09VCBR

Overview
Series Info
Reviews
Literature/Manuals

EJ-B09VCBR

Connections / Discharge (Inches)	3/8" OD x 1/4" ID
Cord Type	Brazil 230 VAC plug
Diaphragm	PTFE + EPDM
Gasket Material	PTFE
Head / Fittings	PVC (Polyvinyl Chloride)
Hz	50/60
Liquid Temperature	32 to 104°F (0 to 40°C)
Maximum Flow (GPH)	0.3

Maximum Pressure (PSI)	175
Maximum Strokes Per Minute	360
Quick Specs	METERING PUMP
Tube Material	Polyethylene (PE)
Valve / Seat / O-Ring	CE / FKM / FKM
Voltage	230

EJ Metering Pumps Information

Product Type
Metering
Features & Benefits
Walchem EJ Chemical Metering Pumps Features & Benefits High Speed Performance The EJ Series operate at 360 strokes-per-minute, providing high resolution chemical feed and high turndown capability. Most competitive products operate at slower speeds, resulting in slug feeding, accelerated diaphragm wear and poor feed control. Universal Voltage The Universal Voltage Function enables the EJ Series to operate at any AC voltage. The EJ Series also conform to global standards. External Control The EJ Series have both digital input and Stop/Start inputs built into the pump, enabling either proportional or On/Off control. IP65 Equivalent Protection A robust housing protects the pump from normal wear. Mounting the Digital Display and Key Pad control within the drive housing creates a highly water resistant design. A clear cover further protects the pump from liquids.
General Description
Walchem EJ Series General Notes 1. All pumps include a Manual Air Vent Valve with the exception of the FC and SH-N Liquid Ends . 2. All pumps include on foot valve, one injection valve, 20ft. of polyethylene tubing and a ceramic weight with the exception of SH Liquid Ends. (E90495 Input connector sold separately) 3. FC and SH pumps have ¼"NPTF connections. FC pumps are supplied with additional tubing compression fittings. 4. PA/TA Liquid ends use AFLAS™ o-rings and PCTFE Seats. 5. The Multi-Function Valve is made of PVDF/FEPM/PTFE materials.
