Stenner Econ Vaccinator Series Peristaltic Metering Pumps Brochure Information

Simplifying Livestock and Poultry Vaccination

The Stenner Econ Vaccinator™ Series was developed to make waterline vaccination easier, more accurate, and less labor intensive. Designed specifically for livestock and poultry operations, the Vaccinator delivers one gallon of liquid oral vaccine over a six-hour period, ensuring treatment is introduced consistently through the drinking water system.

Unlike traditional proportioners that require bypass plumbing and pre-mixed stock solutions, the Vaccinator injects directly into the water line. This helps maintain normal water flow while eliminating the time and effort required to measure and mix solutions before treatment.

The pump is factory programmed with a built-in six-hour timer that automatically shuts the system off when dosing is complete. This automatic operation helps simplify vaccination procedures and provides confidence that the correct amount of product has been delivered.

The Vaccinator utilizes Stenner's proven peristaltic pump design, which keeps the solution contained within the tubing path. Because the solution does not pass through moving mechanical components, the pump can handle challenging products while remaining reliable and easy to maintain. The self-priming design also prevents issues with loss of prime or vapor lock and does not require a foot valve for startup.

Key Benefits

– Consistently delivers 1 gallon over a 6-hour cycle

– Direct injection into the water line

– Automatic shutoff after the dosing cycle

– Eliminates pre-measuring stock solutions

– Helps reduce labor requirements

– Self-priming operation

– Handles off-gassing solutions without vapor lock

– Compact enclosed housing for indoor or outdoor use

– Reliable brushless motor

Routine maintenance is simple thanks to Stenner's patented quick-release pump head, which allows tube replacement without tools. This helps minimize downtime and keeps the system ready for future vaccination events.

Performance Highlights

– Up to 0.36 oz/min output

– Up to 80 PSI operating pressure

– 25-foot maximum suction lift

– ±2% output reproducibility

– Indoor/outdoor rated construction

– Available in 120V and 230V models

For producers seeking a simple and dependable way to deliver liquid oral vaccines through the water system, the Stenner Econ Vaccinator™ Series provides accurate dosing, straightforward operation, and reduced labor compared to traditional proportioning methods.
