0161-0102-0100
March Pumps 0161-0102-0100 Series 10 Chemical Pump, Model Number Flanged TE-10P-MD with Conduit Box, VFD Capable. 10 HP (Horsepower), 230/460V, 3 Phase (3 Ph), 50/60 Hz, 3450 RPM, TEFC Motor. Wet End Materials: Polypropylene(Front Housing, Rear Housing, Impeller), Viton (Gasket), Carbon (Bushing), Ceramic (Shaft, Thrust Washers), 3" ANSI Class 150 Flange Suction & 2" ANSI Class 150 Flange Discharge. 200 GPM (Gallons Per Minute) Max Flow, Heads to 160 ft., 75 PSI Max Pressure, and 160°F Liquid Temperature.
$6,319.28
- Best Price Guarantee!
- 1263PumpPoints
Ships within 1 business day (in-stock items). Delivery typically 1–5 business days.
- Overview
- Reviews
- Literature/Manuals
- Repair Parts
0161-0102-0100
March Pumps 0161-0102-0100 Series 10 Chemical Pump, Model Number Flanged TE-10P-MD with Conduit Box, VFD Capable. 10 HP (Horsepower), 230/460V, 3 Phase (3 Ph), 50/60 Hz, 3450 RPM, TEFC Motor. Wet End Materials: Polypropylene(Front Housing, Rear Housing, Impeller), Viton (Gasket), Carbon (Bushing), Ceramic (Shaft, Thrust Washers), 3" ANSI Class 150 Flange Suction & 2" ANSI Class 150 Flange Discharge. 200 GPM (Gallons Per Minute) Max Flow, Heads to 160 ft., 75 PSI Max Pressure, and 160°F Liquid Temperature.
| Bushing | Carbon |
| Discharge NPT (Inches) | 2" ANSI Class 150 Flange |
| Flange | ANSI Class 150 |
| Gasket Material | Viton |
| Heads To (Feet) | 160 ft. (48.7 m) |
| Housing Material | Polypropylene |
| HP | 10 HP |
| Hz | 50/60 Hz |
| Impeller Material | Polypropylene |
| Includes | Conduit Box |
| KW | 7.4 kW |
| Liquid End Configuration | Polypropylene(Front Housing, Rear Housing, Impeller), Viton (Gasket), Carbon (Bushing), Ceramic (Shaft, Thrust Washers) |
| Liquid Temperature | 160°F (71°C) |
| Max Amps | 23.2-11.6 A |
| Maximum Flow (GPM) | 200 GPM (757 LPM) |
| Maximum Pressure (PSI) | 75 PSI (5.2 Bar) |
| Model Number | Flanged TE-10P-MD |
| Motor | 0161-0012-1000 |
| Motor Enclosure Type | TEFC - Totally Enclosed Fan Cooled |
| Motor Shaft Material | Ceramic |
| Phase | 3 Ph (Three Phase) |
| Product Notes | VFD Capable |
| Quick Specs | Flanged TE-10P-MD 3Ph 10HP |
| Speed (RPM) | 3450 RPM |
| Suction NPT (Inches) | 3" ANSI Class 150 Flange |
| Voltage | 230/460V |
| Type | Title | Link | |
|---|---|---|---|
March Pumps Series 10 Chemical Pumps Manual | View | ||
Repair Parts for 0161-0102-0100
| Product | qty. | shipping | price | ||
|---|---|---|---|---|---|
 | 0160-0029-1000 | Ships in | $1.70 | ||
| 0160-0030-1000 | Ships in | $0.85 | ||
 | 0161-0063-0100 | Ships in | $1,110.10 | ||
| 0161-0043-1000 | Ships in | $143.65 | ||
| 0161-0001-1000 | Ships in | $66.30 | ||
| 0161-0002-1000 | Ships in | $178.50 | ||
| 0161-0053-0300 | Ships in | $2,265.25 | ||
| 0161-0057-1000 | Ships in | $459.85 | ||
| 0161-0031-0100 | Ships in | $1,698.30 | ||
| 0161-0007-0010 | Ships in | $474.30 | ||
| 0160-0031-1000 | Ships in | $3.40 | ||
| 0161-0012-1000 | Ships in | $2,458.20 | ||
| 0161-0040-1100 | Ships in | $266.05 | ||
