Image shown may not be actual product

PV52MF

0 reviews

Goulds PV52MF RGS 2012 Series Residential Grinder Pump, .5 HP, 3400 RPM, 115 Volt, 60 Hz, Single Phase, 2" Discharge, 6.5 Max Amps, 20' Cord Length, 2" Solids Handling

Call for Pricing

Best Price Guarantee!

Item: PV52MF

Overview
Series Info
Reviews
Literature/Manuals
Repair Parts

PV52MF

Goulds PV52MF RGS 2012 Series Residential Grinder Pump, .5 HP, 3400 RPM, 115 Volt, 60 Hz, Single Phase, 2" Discharge, 6.5 Max Amps, 20' Cord Length, 2" Solids Handling

Capacities (GPM)	100
Cord Length	20'
Discharge NPT (Inches)	2"
Float Switch Style	Plug / No Switch
Heads To (Feet)	22' (6.7m)
HP	.5
Hz	60
Max Amps	6.5
Maximum Operating Temperature	104º F (40º C) continuous when fully submerged

Minimum Basin Diameter	18"
Phase	1 Ph (Single Phase)
Quick Specs	.5HP 1/60/230 6.5MA
Solids (Inches)	2" (50 mm)
Speed (RPM)	3400
UPC	69766643275
Voltage	115

PV Submersible Vortex Sewage Pump Series Information

Features & Benefits
Goulds PV Pump Series Range of Features: Corrosion resistant construction Cast iron body Thermoplastic impeller and cover. Upper sleeve and lower heavy duty ball bearing construction. Motor is permanently lubricated for extended service life. Powered for continuous operation. Vortex impeller is recessed to allow free flow through casing. All ratings are within the working limits of the motor. Replaceable power cord, 10' and 20' standard lengths, heavy duty 16/3 SJTW with NEMA three prong, 115 or 230 volt grounding plug. Complete unit is heavy duty, portable and compact. Mechanical seal is carbon, ceramic, BUNA and stainless steel. Stainless steel fasteners
General Description
Goulds PV Submersible Vortex Sewage Pump Specifications: • Discharge: 2" NPT • Maximum capacity: 100 GPM • Maximum head: 22' TDH • Vortex Impeller • Solids handling: 2" maximum sphere. • Temperature: 104º F (40º C) maximum, continuous when fully submerged. • Automatic models include a float switch. • Manual models available.
Materials of Construction
AISI 300 series stainless

0 Reviews

Add a Review

You need to sign in to add a review.

Type	Title		Link
	Goulds Pumps PVS Submersible Vortex Sewage Pump Manual		View
	Goulds Pumps PVS Submersible Vortex Sewage Pump Repair Parts		View

Repair Parts for PV52MF

	shipping	price
6K168	Lead Time TBD	$7.70	Select item
15K57	Lead Time TBD	$133.70	Select item
13K152	Lead Time TBD	Call for pricing
4K243	Lead Time TBD	$30.80	Select item
13K221	Lead Time TBD	$4.20	Select item
13K220	Lead Time TBD	$4.20	Select item
5K321	Ships in	$26.60	Select item

0 items selected.Add items to cart
