Goulds PV41MF RGS 2012 Series Residential Grinder Pump, .4 HP, 3400 RPM, 115 Volt, 60 Hz, Single Phase, 2" Discharge, Call for Max Amps, 10' Cord Length, 2" Solids Handling
|Discharge NPT (Inches)||2"|
|Heads To (Feet)||22'|
|Max Amps||Call for|
|Maximum Operating Temperature||104º F (40º C) continuous when fully submerged|
|Minimum Basin Diameter||18"|
|Quick Specs||.4HP 1/60/115|
|Features & Benefits|
|Goulds PV Pump Series Range of Features:|
Corrosion resistant construction
Cast iron body
Thermoplastic impeller and cover.
Upper sleeve and lower heavy duty ball bearing construction.
Motor is permanently lubricated for extended service life.
Powered for continuous operation.
Vortex impeller is recessed to allow free flow through casing.
All ratings are within the working limits of the motor.
Replaceable power cord, 10' and 20' standard lengths, heavy duty 16/3 SJTW with NEMA three prong, 115 or 230 volt grounding plug.
Complete unit is heavy duty, portable and compact.
Mechanical seal is carbon, ceramic, BUNA and stainless steel.
Stainless steel fasteners
|Goulds PV Submersible Vortex Sewage Pump Specifications: |
• Discharge: 2" NPT
• Maximum capacity: 100 GPM
• Maximum head: 22' TDH
• Vortex Impeller
• Solids handling: 2" maximum sphere.
• Temperature: 104º F (40º C) maximum, continuous when fully submerged.
• Automatic models include a float switch.
• Manual models available.
|Materials of Construction|
|AISI 300 series stainless|
