Finish Thompson FTI Pump with motor VKC8P12CVVN355C07 Vertical Centrifugal, VKC Series Plastic Mag Drive, VKC8, 1 1/2" Suction, 1" Discharge, FKM O-Ring, 3.50" Impeller, 60 psi, 67 GPM
Finish Thompson FTI Pump with motor VKC8P12CVVN355C07 Vertical Centrifugal, VKC Series Plastic Mag Drive, VKC8, 1 1/2" Suction, 1" Discharge, FKM O-Ring, 3.50" Impeller, 60 psi, 67 GPM
Bushing | Carbon |
Column Length | 12" |
Connection Type | NPT |
Discharge NPT (Inches) | 1" |
Heads To (Feet) | 43 |
HP | 0.75 |
Hz | 50/60 |
Impeller Size (Inches) | 3.5" (3 1/2") |
Material | Polypropylene (PPG) |
Maximum Flow (GPM) | 67 |
Maximum Operating Temperature | 140° F (60° C) |
Maximum Pressure (PSI) | 60 psi (413 kPa) |
Motor | 3/4hp/3450/3ph/50-60Hz/E/56C/230-460V |
Motor Frame Size | 56C |
Phase | 3 |
Pressure Rating BAR | 4.13 bar |
Spec. Gravity | up to 1.8 |
Speed (RPM) | 3450 |
Suction NPT (Inches) | 1-1/2" |
Valve/Seat/O-Ring | FKM |
Voltage | 230/460 |
Features & Benefits |
---|
VKC Vertical Mag Drive Pumps Feature: • Utilizes powerful neodymium magnets • Non-aerating (no micro-bubbles) • Reduced environmental emissions • No wetted shaft bearings • Mounts inside or outside of tank • Corrosion resistant Polypropylene or PVDF construction • Accepts standard NEMA or IEC motors • Modular build: in 6” increments from 12” (30 cm) to 60” (152 cm) • Up to 1.8 specific gravity • Maximum temperature 140oF (60oC) • Maximum working pressure: 60 psi |
General Description |
VKC Typical Applications: • High pressure/low flow chemical processing, spraying, bulk unload, and tank transfer applications • Plating recirculation/filtration, PCB etching and rinse • Water/waste water treatment, wet scrubber • Laboratory, pharmaceutical, photo processing |
