• Finish Thompson Wet End Assembly UC436EOCSSVS625 Mag Drive Pumps

Image shown may not be actual product

Finish Thompson FTI

UC436EOCSSVS625

0 reviews

Finish Thompson FTI Wet End Assembly UC436EOCSSVS625 Centrifugal Mag Drive, UC Series Heavy Duty, UC436 ULTRA Chem, 4" Suction, 3" Discharge, FKM O-Ring, 6.25" Impeller Size, 300 psi, 670 GPM

Item: UC436EOCSSVS625
  • Overview
  • Series Info
  • Reviews
  • Literature/Manuals

UC436EOCSSVS625

Finish Thompson FTI Wet End Assembly UC436EOCSSVS625 Centrifugal Mag Drive, UC Series Heavy Duty, UC436 ULTRA Chem, 4" Suction, 3" Discharge, FKM O-Ring, 6.25" Impeller Size, 300 psi, 670 GPM

BushingSiC
Discharge NPT (Inches)3"
FlangeANSI 150#
Heads To (Feet)190
Impeller Size (Inches)6.25"
Magnetto 75hp
Maximum Flow (GPM)670
Maximum Operating Temperature250°F (121°C)
Maximum Pressure (PSI)300 psi
Pressure Rating BAR20.7 bar
Shaft Seal MaterialSiC
Spec. Gravityup to 1.8
Suction NPT (Inches)4"
Thrust RingSiC
Valve/Seat/O-RingFKM

UC Heavy Duty Magnetic Drive Centrifugal Pumps Information

Features & Benefits
UC Pump Series Typical Pumping Applications:
• Chemical manufacturing, blending, distribution
• Water treatment
• Plating and metal finishing
• Paper mills
• Fume scrubbers
• Metals manufacturing
• Electronics
• Pharmaceuticals
• Biodiesel

Typical Chamicals:
• Sodium hydroxide, sulfuric acid, hydrochloric acid, sodium hypochlorite, plating solutions, corrosive blends, wastewater, solvents
General Description
UC Heavy Duty Magnetic Drive Centrifugal Pump Capabilities:
Casing: ANSI/ASME B73.1m
Max. Working
Pressure: to 300 psi (20 Bar)
Max. Temp.: 250oF (121oC)
Max. Viscocity: 200 cP
Specific Gravity: over 1.8
Flanges: ANSI or ISO
Casing: ANSI/ASME B73.1m
Motor Frames:
NEMA: 143 through 365
IEC: 90 through 225
