SP11V Finish Thompson Pump End Self Priming FTI

Features & Benefits
SP Sealless Self Priming Centrifufal Pumps Features & Capabilities: + Self-priming, magnetic drive + Five-year warranty + Provides up to 25 ft. (7.6 m) lift or equivalent + Primes 15 ft. (4.6 m) in < 2 minutes with maximum diameter impeller + Retains fluid for re-priming when shut off without a check valve + Extended run dry ability (with carbon bushing) + High operating efficiency + Polypropylene or PVDF construction + Powerful neodymium magnets + Close-coupled design + Threaded (NPT or BSP), union or flange connections + Back pullout design + Mounts to NEMA and (B5 & B14) IEC motor frames + Easy set measurement free drive + ISO 1940 G2.5 balancing + CE certified + High working pressure up to 80 psi (5.5 bar) + Specific gravity over 1.8 + Polypropylene—180o F (82o C) + PVDF—220o F (104o C)
General Description
FTI SP Series Applications: + Rail cars + Tanker trucks + Tanks with an opening on top + Bulk storage to day or process tank transfer + Sumps and reservoirs + Below grade storage tanks + Over-the-wall applications + When run-dry protection is needed + and many more!

Maximum Operating Temperature	220°F (104°C)
Maximum Pressure (PSI)	90 PSI
Motor Frame Size	56C
Pressure Rating BAR	6.2 bar
Spec. Gravity	up to 1.8
Suction NPT (Inches)	1-1/2"
Valve/Seat/O-Ring	FKM

Type	Title		Link
	DB, SP, MSDB Series Pumps Brochure (2022)		View
	Chemical Processing Applications Flyer (2022)		View
	SP11 Series Pumps Datasheet (2022)		View
	DB & SP Series Baseplates Datasheet (2022)		View
	DB, SP, UC, Series M20 Power Monitor Datasheet (2022)		View
	SP Series Sealless Self Prime Pumps Performance Curves (2022)		View
	SP11 SP15 Series Pumps Installation & Operation Manual (2022)		View

	shipping	price
105862-1	Ships in	$1,929.45	Select item
105919	Ships in	$3.65	Select item
106143-1	Ships in	$76.00	Select item
106155	Ships in	$0.37	Select item
105863-1	Ships in	$140.60	Select item
J103477	Ships in	$30.40	Select item
105913-3	Ships in	$1,008.90	Select item
J100977	Ships in	$264.10	Select item
105716	Ships in	$14.44	Select item
105689-4	Ships in	$411.35	Select item
107406	Ships in	$249.85	Select item
107279-NEP	Ships in	$228.00	Select item
107228-1	Ships in	$183.35	Select item
107283	Ships in	$8.42	Select item
106890-1	Ships in	$77.90	Select item
106374	Ships in	$5.92	Select item
105878	Ships in	$760.95	Select item
J101084	Ships in	$1.21	Select item
105708	Ships in	$6.02	Select item
106211-FTI	Ships in	$196.65	Select item
105758	Ships in	$14.67	Select item
105773	Ships in	$12.42	Select item
105752	Ships in	$38.95	Select item
J104206	Ships in	$6.22	Select item
J104207	Ships in	$6.22	Select item
107288	Ships in	$14.86	Select item
107290-NEP	Ships in	$33.00	Select item
J104203	Ships in	$3.73	Select item
J104204	Ships in	$3.73	Select item
107287-NEP	Ships in	$33.00	Select item
105768	Ships in	$12.04	Select item
J103847	Ships in	$4.73	Select item
107285	Ships in	$14.38	Select item

SP11V
