Finish Thompson SP11V-M227 Pump, FTI SP11 Magnetic Drive Centrifugal SP Series Self-Priming Sealless Pumps, 1/2 HP, 208-230-460 Volt, 60 HZ, 3 Phase, 1 1/2" Suction, 1 1/2" Discharge, FKM O-Ring, PVDF, 104 GPM, 90 PSI, 68 Feet of Head
Finish Thompson SP11V-M227 Pump, FTI SP11 Magnetic Drive Centrifugal SP Series Self-Priming Sealless Pumps, 1/2 HP, 208-230-460 Volt, 60 HZ, 3 Phase, 1 1/2" Suction, 1 1/2" Discharge, FKM O-Ring, PVDF, 104 GPM, 90 PSI, 68 Feet of Head
Bushing | Carbon |
Connection Type | NPT |
Discharge NPT (Inches) | 1-1/2" |
Heads To (Feet) | 68 |
HP | 0.5 |
Hz | 60 |
Impeller Size (Inches) | 4.625" (4 5/8") |
Magnet | 6-pole |
Material | PVDF |
Maximum Flow (GPM) | 104 |
Maximum Operating Temperature | 220°F (104°C) |
Maximum Pressure (PSI) | 90 PSI |
Motor Frame Size | 56C |
Phase | 3 |
Pressure Rating BAR | 6.2 bar |
Spec. Gravity | up to 1.8 |
Speed (RPM) | 3450 |
Suction NPT (Inches) | 1-1/2" |
Valve/Seat/O-Ring | FKM |
Voltage | 208/230/460 |
Features & Benefits |
---|
SP Sealless Self Priming Centrifufal Pumps Features & Capabilities: + Self-priming, magnetic drive + Five-year warranty + Provides up to 25 ft. (7.6 m) lift or equivalent + Primes 15 ft. (4.6 m) in < 2 minutes with maximum diameter impeller + Retains fluid for re-priming when shut off without a check valve + Extended run dry ability (with carbon bushing) + High operating efficiency + Polypropylene or PVDF construction + Powerful neodymium magnets + Close-coupled design + Threaded (NPT or BSP), union or flange connections + Back pullout design + Mounts to NEMA and (B5 & B14) IEC motor frames + Easy set measurement free drive + ISO 1940 G2.5 balancing + CE certified + High working pressure up to 80 psi (5.5 bar) + Specific gravity over 1.8 + Polypropylene—180o F (82o C) + PVDF—220o F (104o C) |
General Description |
FTI SP Series Applications: + Rail cars + Tanker trucks + Tanks with an opening on top + Bulk storage to day or process tank transfer + Sumps and reservoirs + Below grade storage tanks + Over-the-wall applications + When run-dry protection is needed + and many more! |
Septic / Sump Tank
2100 productsTank Car
2100 productsType | Title | Link | |
---|---|---|---|
DB, SP, MSDB Series Pumps Brochure (2022) | View | ||
Chemical Processing Applications Flyer (2022) | View | ||
SP11 Series Pumps Datasheet (2022) | View | ||
DB & SP Series Baseplates Datasheet (2022) | View | ||
DB, SP, UC, Series M20 Power Monitor Datasheet (2022) | View | ||
SP Series Sealless Self Prime Pumps Performance Curves (2022) | View | ||
SP11 SP15 Series Pumps Installation & Operation Manual (2022) | View |
Product | qty. | shipping | price | ||
---|---|---|---|---|---|
105862-1 | Ships in | $1,929.45 | |||
105919 | Ships in | $3.65 | |||
106143-1 | Ships in | $76.00 | |||
106155 | Ships in | $0.37 | |||
105863-1 | Ships in | $140.60 | |||
J103477 | Ships in | $30.40 | |||
105913-3 | Ships in | $1,008.90 | |||
J100977 | Ships in | $264.10 | |||
105716 | Ships in | $14.44 | |||
105689-4 | Ships in | $411.35 | |||
107406 | Ships in | $249.85 | |||
107279-NEP | Ships in | $228.00 | |||
107228-1 | Ships in | $183.35 | |||
107283 | Ships in | $8.42 | |||
106890-1 | Ships in | $77.90 | |||
106374 | Ships in | $5.92 | |||
105878 | Ships in | $760.95 | |||
J101084 | Ships in | $1.21 | |||
105708 | Ships in | $6.02 | |||
106211-FTI | Ships in | $196.65 | |||
105758 | Ships in | $14.67 | |||
105773 | Ships in | $12.42 | |||
105752 | Ships in | $38.95 | |||
J104206 | Ships in | $6.22 | |||
J104207 | Ships in | $6.22 | |||
107288 | Ships in | $14.86 | |||
107290-NEP | Ships in | $33.00 | |||
J104203 | Ships in | $3.73 | |||
J104204 | Ships in | $3.73 | |||
107287-NEP | Ships in | $33.00 | |||
105768 | Ships in | $12.04 | |||
J103847 | Ships in | $4.73 | |||
107285 | Ships in | $14.38 |
