Finish Thompson SP10V-M614 Pump, FTI SP10 Magnetic Drive Centrifugal SP Series Self-Priming Sealless Pumps, 1/8 HP, 230 Volt, 50-60 HZ, 1 Phase, 1" Suction, 1" Discharge, FKM O-Ring, PVDF, 55 GPM, 80 PSI, 63 Feet of Head
Finish Thompson SP10V-M614 Pump, FTI SP10 Magnetic Drive Centrifugal SP Series Self-Priming Sealless Pumps, 1/8 HP, 230 Volt, 50-60 HZ, 1 Phase, 1" Suction, 1" Discharge, FKM O-Ring, PVDF, 55 GPM, 80 PSI, 63 Feet of Head
Bushing | Carbon |
Connection Type | NPT |
Discharge NPT (Inches) | 1" |
Heads To (Feet) | 63 |
HP | 0.125 |
Hz | 50/60 |
Impeller Size (Inches) | 4.1875" (4 3/16") |
Magnet | 10-pole |
Material | PVDF |
Maximum Flow (GPM) | 55 |
Maximum Operating Temperature | 220°F (104°C) |
Maximum Pressure (PSI) | 80 PSI (5.5 Bar) |
Motor Frame Size | 56C |
Phase | 1 |
Pressure Rating BAR | 5.5 bar |
Spec. Gravity | up to 1.8 |
Speed (RPM) | 2850/3450 |
Suction NPT (Inches) | 1" |
Valve/Seat/O-Ring | FKM |
Voltage | 230 |
Features & Benefits |
---|
SP Sealless Self Priming Centrifufal Pumps Features & Capabilities: + Self-priming, magnetic drive + Five-year warranty + Provides up to 25 ft. (7.6 m) lift or equivalent + Primes 15 ft. (4.6 m) in < 2 minutes with maximum diameter impeller + Retains fluid for re-priming when shut off without a check valve + Extended run dry ability (with carbon bushing) + High operating efficiency + Polypropylene or PVDF construction + Powerful neodymium magnets + Close-coupled design + Threaded (NPT or BSP), union or flange connections + Back pullout design + Mounts to NEMA and (B5 & B14) IEC motor frames + Easy set measurement free drive + ISO 1940 G2.5 balancing + CE certified + High working pressure up to 80 psi (5.5 bar) + Specific gravity over 1.8 + Polypropylene—180o F (82o C) + PVDF—220o F (104o C) |
General Description |
FTI SP Series Applications: + Rail cars + Tanker trucks + Tanks with an opening on top + Bulk storage to day or process tank transfer + Sumps and reservoirs + Below grade storage tanks + Over-the-wall applications + When run-dry protection is needed + and many more! |
Septic / Sump Tank
2100 productsTank Car
2100 productsType | Title | Link | |
---|---|---|---|
DB, SP, MSDB Series Pumps Brochure (2022) | View | ||
Chemical Processing Applications Flyer (2022) | View | ||
SP10 Series Pumps Datasheet (2022) | View | ||
DB & SP Series Baseplates Datasheet (2022) | View | ||
DB, SP, UC, Series M20 Power Monitor Datasheet (2022) | View | ||
SP Series Sealless Self Prime Pumps Performance Curves (2022) | View | ||
SP10 Series Pumps Installation & Operation Manual (2022) | View |
Product | qty. | shipping | price | ||
---|---|---|---|---|---|
106564-1 | Ships in | $1,044.05 | |||
106143-1 | Ships in | $76.00 | |||
106155 | Ships in | $0.37 | |||
106298 | Ships in | $5.28 | |||
106975-NEP | Ships in | Call for pricing | |||
106563-1 | Ships in | $119.70 | |||
106361-5 | Ships in | $506.35 | |||
J102387 | Ships in | $150.10 | |||
106235-7 | Ships in | $203.30 | |||
106551 | Ships in | $4.52 | |||
106246-1 | Ships in | $123.50 | |||
J103954 | Ships in | $2.55 | |||
106248-1 | Ships in | $50.35 | |||
106374 | Ships in | $5.92 | |||
106283-2 | Ships in | $388.55 | |||
105708 | Ships in | $6.02 | |||
J102789 | Ships in | $0.91 | |||
J102282 | Ships in | $0.10 | |||
105767 | Ships in | $0.14 | |||
105767 | Ships in | $0.14 | |||
J102282 | Ships in | $0.10 | |||
105770 | Ships in | $0.59 | |||
J100114 | Ships in | $0.60 | |||
J100115 | Ships in | $0.16 | |||
J100128 | Ships in | $0.11 |
