Pump End MSVKCV42CVVN15C Finish Thompson FTI MSVKC

Features & Benefits
MSVKC Vertical Multi Stage Mag Drive Pumps Feature: • Sealless mag drive technology - eliminates microbubbles • Multi-Stage design: Generates increased head at low flow rates, low power consumption, wide hydraulic envelope allows for mix and match impeller sizes • Unique interconnecting drive shaft - transmits torque from magnetic coupling to first stage impeller • Independent thrust bearings at each stage for maximum reliability • Polypropylene or PVDF construction • Titanium, Hastelloy C or PVDF housing bolts • Custom mounting plates available • Accepts standard NEMA 56C or IEC 63, 71 and 80 with B14 frame motors • Maximum working pressure 80 psi (5.4 bar) • Maximum temperature: 140oF (60oC) • Maximum flow 60 gpm (13.6 m3/hr.), maximum head 100 ft. (20 m)
General Description
MSVKC Typical Applications: • High pressure/low flow chemical processing, spraying, bulk unload, and tank transfer applications • Plating recirculation/filtration, PCB etching and rinse • Water/waste water treatment, wet scrubber • Laboratory, pharmaceutical, photo processing

Maximum Operating Temperature	140° F (60° C)
Maximum Pressure (PSI)	80 PSI (5.5 Bar)
Motor Frame Size	56C
Pressure Rating BAR	5.5 bar
Spec. Gravity	up to 1.8
Suction NPT (Inches)	1-1/2"
Valve/Seat/O-Ring	FKM

Type	Title		Link
	MSVKC Vertical Multistage Pumps Datasheet (2022)		View
	MSVKC Vertical Pumps Installation & Operation Manual (2022)		View

	shipping	price
J100113	Ships in	$0.09	Select item
J100672	Ships in	$0.06	Select item
J100128	Ships in	$0.11	Select item
J100115	Ships in	$0.16	Select item
J103161	Ships in	$1.87	Select item
J100114	Ships in	$0.60	Select item
105611	Ships in	$184.30	Select item
J103306	Ships in	$45.60	Select item
J103307	Ships in	$53.20	Select item
M1012119-4	Ships in	Call for pricing
A101989-20	Ships in	$627.95	Select item
J103515	Ships in	$4.83	Select item
A102271-2	Ships in	$345.80	Select item
J102389	Ships in	$5.42	Select item
A103269-4	Ships in	$860.70	Select item
J102387	Ships in	$150.10	Select item
A101983-6	Ships in	$209.95	Select item
J101606	Ships in	$99.75	Select item
A103205-2	Ships in	Call for pricing
J102447	Ships in	$11.07	Select item
A103270-4	Ships in	$374.30	Select item
A103195-2	Ships in	$414.20	Select item
J103926	Ships in	$72.20	Select item
J103159	Ships in	$151.05	Select item
J103166	Ships in	$344.85	Select item
A102485	Ships in	$95.95	Select item
M101982-2	Ships in	$310.65	Select item
J103157	Ships in	$111.15	Select item
J103175	Ships in	$3.62	Select item
J100135	Ships in	$0.33	Select item
105462	Ships in	$137.75	Select item
105463-NEP	Ships in	$65.00	Select item
J103638	Ships in	$0.07	Select item

MSVKCV42CVVN15C
