• Finish Thompson Pump w/ motor MSVKCV18CVVN15C33 Vertical Multistage

Image shown may not be actual product

Finish Thompson FTI

MSVKCV18CVVN15C33

0 reviews

Finish Thompson FTI Pump with motor MSVKCV18CVVN15C33 Vertical Multistage Centrifugal, VKC Series Plastic Mag Drive, MSVKC, 1 1/2" Suction, 1" Discharge, FKM O-Ring, 3.88" Impeller, 80 psi, 61 GPM

$3,408.80

Item: MSVKCV18CVVN15C33
  • Overview
  • Series Info
  • Reviews
  • Literature/Manuals

MSVKCV18CVVN15C33

Finish Thompson FTI Pump with motor MSVKCV18CVVN15C33 Vertical Multistage Centrifugal, VKC Series Plastic Mag Drive, MSVKC, 1 1/2" Suction, 1" Discharge, FKM O-Ring, 3.88" Impeller, 80 psi, 61 GPM

BushingCarbon
Column Length18"
Connection TypeNPT
Discharge NPT (Inches)1"
Heads To (Feet)99
HP3
Hz60
Impeller Size (Inches)3.88"
MaterialPVDF
Maximum Flow (GPM)61
Maximum Operating Temperature140°F (60°C)
Maximum Pressure (PSI)80 psi
Motor3hp/3450/3ph/60Hz/T/56C/230-460V
Motor Frame Size56C
Phase3
Pressure Rating BAR5.5 bar
Spec. Gravityup to 1.8
Speed (RPM)3450
Suction NPT (Inches)1 1/2"
Valve/Seat/O-RingFKM
Voltage230-460

MSVKC Vertical Multistage Mag Drive Pumps Information

Features & Benefits
MSVKC Vertical Multi Stage Mag Drive Pumps Feature:
• Sealless mag drive technology - eliminates microbubbles
• Multi-Stage design: Generates increased head at low flow rates, low power consumption, wide hydraulic envelope allows for mix and match impeller sizes
• Unique interconnecting drive shaft - transmits torque from magnetic coupling to first stage impeller
• Independent thrust bearings at each stage for maximum reliability
• Polypropylene or PVDF construction
• Titanium, Hastelloy C or PVDF housing bolts
• Custom mounting plates available
• Accepts standard NEMA 56C or IEC 63, 71 and 80 with B14 frame motors
• Maximum working pressure 80 psi (5.4 bar)
• Maximum temperature: 140oF (60oC)
• Maximum flow 60 gpm (13.6 m3/hr.), maximum head 100 ft. (20 m)
General Description
MSVKC Typical Applications:
• High pressure/low flow chemical processing, spraying, bulk unload, and tank transfer applications
• Plating recirculation/filtration, PCB etching and rinse
• Water/waste water treatment, wet scrubber
• Laboratory, pharmaceutical, photo processing

Categories

0 Reviews

Add a Review

You need to sign in to add a review.

TypeTitleLink

VKC MSVKC Vertical Mag Drive Pump Datasheet

View

VKC MSVKC Series Pump Curves

View

MSVKC Pump Datasheet

View

HD Product Demos & More

Stay tuned for releases of new product reviews and videos on our YouTube channel!
