Image shown may not be actual product
Finish Thompson FTI Pump with motor MSKCPCVN15C22 Sealless Non-Metallic Mag Drive Centrifugal, MSKC Series Multistage Pumps, 1 1/2" Suction, 1" Discharge, FKM O-Ring, Polypropylene
Finish Thompson FTI Pump with motor MSKCPCVN15C22 Sealless Non-Metallic Mag Drive Centrifugal, MSKC Series Multistage Pumps, 1 1/2" Suction, 1" Discharge, FKM O-Ring, Polypropylene
Bushing | Carbon |
Connection Type | NPT |
Discharge NPT (Inches) | 1" |
Heads To (Feet) | 99 |
HP | 2 |
Hz | 60 |
Impeller Size (Inches) | 3.875" (3 7/8") |
Material | Polypropylene (PPG) |
Maximum Operating Temperature | 180°F (82°C) |
Maximum Pressure (PSI) | 80 PSI (5.5 Bar) |
Motor | 2hp/3450/1ph/60Hz/T/56C/115-230V |
Motor Frame Size | 56C |
Phase | 1 |
Pressure Rating BAR | 5.5 bar |
Speed (RPM) | 3450 |
Suction NPT (Inches) | 1-1/2" |
Valve/Seat/O-Ring | FKM |
Voltage | 115/230 |
Features & Benefits |
---|
MSKC Sealless Plastic Multistage Pump Features: • Sealless mag drive technology - eliminates costly seal problems • Multi-Stage design: Generates increased head at low flow rates, low power consumption, wide hydraulic envelope allows for mix and match impeller sizes • Small footprint - avoids large impeller diameters • Unique interconnecting drive shaft - transmits torque from magnetic coupling to first stage impeller • Independent thrust bearings at each stage for maximum reliability • Polypropylene or PVDF construction • Accepts standard NEMA 56C or IEC 71/B14, 80/B14 frame motors • Maximum working pressure 80 psi • Maximum temperature: 180°F (82°C) - Polypropylene 220°F (104°C) - PVDF • Maximum flow 60 gpm (12.8 m3/hr.), maximum head 100 ft. (21.3 m) |
Chemical Delivery / Processing
22853 productsHeat Exchangers
6346 productsManufacturing
20389 productsPharmaceutical / Chemical
15972 productsPlating
23448 productsPulp & Paper
6474 productsSewage / Wastewater
20311 productsWater Transfer
390 productsProduct | qty. | shipping | price | ||
---|---|---|---|---|---|
A103195-1 | Ships in | $183.35 | |||
A103270-1 | Ships in | $248.90 | |||
A103270-3 | Ships in | $380.95 | |||
J102389 | Ships in | $5.42 | |||
J102447 | Ships in | $11.07 | |||
A103205-1 | Ships in | Call for pricing | |||
A103269-1 | Ships in | $615.60 | |||
J102387 | Ships in | $150.10 | |||
107788-1 | Ships in | $110.20 | |||
A101990-15 | Ships in | $580.45 | |||
J104219 | Ships in | $4.00 | |||
J104220 | Ships in | $4.10 | |||
A101991-3 | Ships in | $79.80 | |||
M102351 | Ships in | $239.40 | |||
J103873 | Ships in | $6.42 | |||
J100672 | Ships in | $0.06 | |||
J100113 | Ships in | $0.09 | |||
J102878 | Ships in | $1.26 | |||
J100114 | Ships in | $0.60 | |||
J100115 | Ships in | $0.16 | |||
J100128 | Ships in | $0.11 |
