Finish Thompson FTI Pump with motor MSKCPCVN15C01 Sealless Non-Metallic Mag Drive Centrifugal, MSKC Series Multistage Pumps, 1 1/2" Suction, 1" Discharge, FKM O-Ring, Polypropylene
|Discharge NPT (Inches)||1"|
|Heads To (Feet)||99|
|Impeller Size (Inches)||3.88"|
|Maximum Operating Temperature||180°F (82°C)|
|Maximum Pressure (PSI)||80 PSI|
|Motor Frame Size||56C|
|Pressure Rating BAR||5.5 bar|
|Suction NPT (Inches)||1 1/2"|
|Features & Benefits|
|MSKC Sealless Plastic Multistage Pump Features:|
• Sealless mag drive technology - eliminates costly seal problems
• Multi-Stage design: Generates increased head at low flow rates, low power consumption, wide hydraulic envelope allows for mix and match impeller sizes
• Small footprint - avoids large impeller diameters
• Unique interconnecting drive shaft - transmits torque from magnetic coupling to first stage impeller
• Independent thrust bearings at each stage for maximum reliability
• Polypropylene or PVDF construction
• Accepts standard NEMA 56C or IEC 71/B14, 80/B14 frame motors
• Maximum working pressure 80 psi
• Maximum temperature: 180°F (82°C) - Polypropylene 220°F (104°C) - PVDF
• Maximum flow 60 gpm (12.8 m3/hr.), maximum head 100 ft. (21.3 m)
