Finish Thompson FTI Pump with motor GP32VVB01601812 Sealed Non-Metallic Centrifugal, GP Series Plastic, 3" Suction, 2" Discharge, FKM O-Ring, PVDF, 55 psi, 201 GPM, GP32 Economical Chemical Handling
Finish Thompson FTI Pump with motor GP32VVB01601812 Sealed Non-Metallic Centrifugal, GP Series Plastic, 3" Suction, 2" Discharge, FKM O-Ring, PVDF, 55 psi, 201 GPM, GP32 Economical Chemical Handling
Discharge NPT (Inches) | 2" |
Heads To (Feet) | 123 |
HP | 5 |
Hz | 60 |
Impeller Size (Inches) | 6.125" (6 1/8") |
Material | PVDF |
Maximum Flow (GPM) | 201 |
Maximum Operating Temperature | 220°F (104°C) |
Maximum Pressure (PSI) | 55 psi |
Motor | 5hp/3450/3ph/60Hz/WD/184JM/230-460V |
Motor Frame Size | 143/184JM |
Phase | 3 |
Pressure Rating BAR | 3.8 bar |
Shaft Seal Type | Bellows |
Spec. Gravity | 1.8 |
Speed (RPM) | 3450 |
Suction NPT (Inches) | 3" |
Valve/Seat/O-Ring | FKM |
Voltage | 230/460 |
Features & Benefits |
---|
GP Sealed Plastic Centrifugal Pump Features: • Mechanical seal horizontal centrifugal pump • GF Polypropylene or CF PVDF corrosion resistant construction • Accepts standards NEMA 56C, 145TC, 143-184JM, or IEC 80, 90, 100, and 112 motor frames • Up to 7 1/2 Hp (3.0 kW) motors • Back pull-out feature enables fast access for pump maintenance • Close coupled or pedestal mounted • Bellows, multi-spring or double seals • Carbon, FKM or ceramic standard seal materials • FKM or EPDM o-rings standard • Up to 1.8 specific gravity with no impeller trimming • Port sizes: 1.5” x 1.5”, 2” x 2”, 3” x 2” • Maximum temperature: Polypropylene - 180oF (82oC), PVDF - 220oF (104oC) • Maximum working pressure: 35 psi / 2.4 Bar (GP11), 55 psi / 3.8 Bar (GP22/32) |
General Description |
FTI GP Series Typical Applications: • Chemical processing, spraying, transfer • Plating recirculation/filtration, PCB etching/rinse • Mild corrosive or low budget applications where periodic seal replacement is not an issue |
Chemical Delivery / Processing
22853 productsFiltration Systems
1862 productsManufacturing
20389 productsPlating
23448 productsRecirculation
78 productsSpray Systems
1862 productsProduct | qty. | shipping | price | ||
---|---|---|---|---|---|
A101230-2 | Ships in | $1,985.50 | |||
M100868-2 | Ships in | $362.90 | |||
A101761-1 | Ships in | $486.40 | |||
M100130 | Ships in | $48.45 | |||
M101569 | Ships in | $394.25 | |||
J100122 | Ships in | $439.85 | |||
J100125 | Ships in | $9.51 | |||
J101058 | Ships in | $6.98 | |||
J101257 | Ships in | $2.85 | |||
J101293 | Ships in | $0.08 | |||
J100115 | Ships in | $0.16 | |||
J100129 | Ships in | $9.51 | |||
J101085 | Ships in | $53.20 | |||
J100118 | Ships in | $21.85 | |||
J100132 | Ships in | $0.33 | |||
J100134 | Ships in | $81.70 | |||
M100135 | Ships in | $9.33 | |||
J100114 | Ships in | $0.60 | |||
A100188 | Ships in | $285.00 | |||
M100851 | Ships in | $60.80 | |||
J102112 | Ships in | $5.40 | |||
M100654 | Ships in | $265.05 |
