Pump End GP32PVM016018 Finish Thompson FTI

Features & Benefits
GP Sealed Plastic Centrifugal Pump Features: • Mechanical seal horizontal centrifugal pump • GF Polypropylene or CF PVDF corrosion resistant construction • Accepts standards NEMA 56C, 145TC, 143-184JM, or IEC 80, 90, 100, and 112 motor frames • Up to 7 1/2 Hp (3.0 kW) motors • Back pull-out feature enables fast access for pump maintenance • Close coupled or pedestal mounted • Bellows, multi-spring or double seals • Carbon, FKM or ceramic standard seal materials • FKM or EPDM o-rings standard • Up to 1.8 specific gravity with no impeller trimming • Port sizes: 1.5” x 1.5”, 2” x 2”, 3” x 2” • Maximum temperature: Polypropylene - 180oF (82oC), PVDF - 220oF (104oC) • Maximum working pressure: 35 psi / 2.4 Bar (GP11), 55 psi / 3.8 Bar (GP22/32)
General Description
FTI GP Series Typical Applications: • Chemical processing, spraying, transfer • Plating recirculation/filtration, PCB etching/rinse • Mild corrosive or low budget applications where periodic seal replacement is not an issue

Discharge NPT (Inches)	2"
Heads To (Feet)	123
Impeller Size (Inches)	6.125" (6 1/8")
Material	Polypropylene (PPG)
Maximum Flow (GPM)	201
Maximum Operating Temperature	180°F (82°C)
Maximum Pressure (PSI)	55 psi

Type	Title		Link
	GP Series Pumps Brochure (2022)		View
	GP11, GP22, GP32 Series Pumps Datasheet (2022)		View
	GP Series Pumps Performance Curves (2022)		View
	GP22 & GP32 Series Pumps Installation & Operation Manual (2022)		View

	shipping	price
A101230-1	Ships in	$551.95	Select item
M100868-1	Ships in	$190.95	Select item
M100132	Ships in	$190.95	Select item
M101569	Ships in	$394.25	Select item
J100123	Ships in	$1,919.95	Select item
J100125	Ships in	$9.51	Select item
J101058	Ships in	$6.98	Select item
J101257	Ships in	$2.85	Select item
J101293	Ships in	$0.08	Select item
J100115	Ships in	$0.16	Select item
J100129	Ships in	$9.51	Select item
J101085	Ships in	$53.20	Select item
J100118	Ships in	$21.85	Select item
J100132	Ships in	$0.33	Select item
J100134	Ships in	$81.70	Select item
M100135	Ships in	$9.33	Select item
J100114	Ships in	$0.60	Select item
A100188	Ships in	$285.00	Select item
M100851	Ships in	$60.80	Select item
J102112	Ships in	$5.40	Select item

GP32PVM016018
