GP32PVB01601808 Finish Thompson Pump / Motor FTI

Features & Benefits
GP Sealed Plastic Centrifugal Pump Features: • Mechanical seal horizontal centrifugal pump • GF Polypropylene or CF PVDF corrosion resistant construction • Accepts standards NEMA 56C, 145TC, 143-184JM, or IEC 80, 90, 100, and 112 motor frames • Up to 7 1/2 Hp (3.0 kW) motors • Back pull-out feature enables fast access for pump maintenance • Close coupled or pedestal mounted • Bellows, multi-spring or double seals • Carbon, FKM or ceramic standard seal materials • FKM or EPDM o-rings standard • Up to 1.8 specific gravity with no impeller trimming • Port sizes: 1.5” x 1.5”, 2” x 2”, 3” x 2” • Maximum temperature: Polypropylene - 180oF (82oC), PVDF - 220oF (104oC) • Maximum working pressure: 35 psi / 2.4 Bar (GP11), 55 psi / 3.8 Bar (GP22/32)
General Description
FTI GP Series Typical Applications: • Chemical processing, spraying, transfer • Plating recirculation/filtration, PCB etching/rinse • Mild corrosive or low budget applications where periodic seal replacement is not an issue

Discharge NPT (Inches)	2"
Heads To (Feet)	123
HP	3
Hz	60
Impeller Size (Inches)	6.125" (6 1/8")
Material	Polypropylene (PPG)
Maximum Flow (GPM)	201
Maximum Operating Temperature	180°F (82°C)
Maximum Pressure (PSI)	55 psi
Motor	3hp/3450/3ph/60Hz/E/182JM/230-460V

Type	Title		Link
	GP Series Pumps Brochure (2022)		View
	GP11, GP22, GP32 Series Pumps Datasheet (2022)		View
	GP Series Pumps Performance Curves (2022)		View
	GP22 & GP32 Series Pumps Installation & Operation Manual (2022)		View

	shipping	price
A101230-1	Ships in	$594.70	Select item
M100868-1	Ships in	$207.10	Select item
M100132	Ships in	$207.10	Select item
M101569	Ships in	$425.60	Select item
J100122	Ships in	$474.05	Select item
J100125	Ships in	$10.23	Select item
J101058	Ships in	$7.51	Select item
J101257	Ships in	$3.07	Select item
J101293	Ships in	$0.11	Select item
J100115	Ships in	$0.18	Select item
J100129	Ships in	$10.23	Select item
J101085	Ships in	$57.95	Select item
J100118	Ships in	$24.70	Select item
J100132	Ships in	$0.36	Select item
J100134	Ships in	$89.30	Select item
M100135	Ships in	$10.04	Select item
J100114	Ships in	$0.65	Select item
A100188	Ships in	$306.85	Select item
M100851	Ships in	$65.55	Select item
J102112	Ships in	$5.80	Select item
M100654	Ships in	$285.95	Select item

GP32PVB01601808
