• Finish Thompson Pump End GP22VVB016018

Image shown may not be actual product

Finish Thompson FTI

GP22VVB016018

0 reviews

Finish Thompson FTI Pump End GP22VVB016018 Sealed Non-Metallic Centrifugal, GP Series Plastic, 2" Suction, 2" Discharge, FKM O-Ring, PVDF, 55 psi, 201 GPM, GP22 Economical Chemical Handling

$2,169.60

Item: GP22VVB016018
  • Overview
  • Series Info
  • Reviews
  • Literature/Manuals

GP22VVB016018

Finish Thompson FTI Pump End GP22VVB016018 Sealed Non-Metallic Centrifugal, GP Series Plastic, 2" Suction, 2" Discharge, FKM O-Ring, PVDF, 55 psi, 201 GPM, GP22 Economical Chemical Handling

Discharge NPT (Inches)2"
Heads To (Feet)123
Impeller Size (Inches)6.13"
MaterialPVDF
Maximum Flow (GPM)201
Maximum Operating Temperature220°F (104°C)
Maximum Pressure (PSI)55 psi
Motor Frame Size143/184JM
Pressure Rating BAR3.8 bar
Shaft Seal TypeBellows
Spec. Gravity1.8
Suction NPT (Inches)2"
Valve/Seat/O-RingFKM

GP Sealed Plastic Centrifugal Pump Information

Features & Benefits
GP Sealed Plastic Centrifugal Pump Features:

• Mechanical seal horizontal centrifugal pump
• GF Polypropylene or CF PVDF corrosion resistant construction
• Accepts standards NEMA 56C, 145TC, 143-184JM, or IEC 80, 90, 100, and 112 motor frames
• Up to 7 1/2 Hp (3.0 kW) motors
• Back pull-out feature enables fast access for pump maintenance
• Close coupled or pedestal mounted
• Bellows, multi-spring or double seals
• Carbon, FKM or ceramic standard seal materials
• FKM or EPDM o-rings standard
• Up to 1.8 specific gravity with no impeller trimming
• Port sizes: 1.5” x 1.5”, 2” x 2”, 3” x 2”
• Maximum temperature: Polypropylene - 180oF (82oC), PVDF - 220oF (104oC)
• Maximum working pressure: 35 psi / 2.4 Bar (GP11), 55 psi / 3.8 Bar (GP22/32)
General Description
FTI GP Series Typical Applications:
• Chemical processing, spraying, transfer
• Plating recirculation/filtration, PCB etching/rinse
• Mild corrosive or low budget applications where periodic seal replacement is not an issue

Categories

0 Reviews

Add a Review

You need to sign in to add a review.

TypeTitleLink

GP Series Pump Brochure

View

GP Series Pump Curves

View

GP Series Pump Datasheet

View

GP11 Series Pump Manual

View

GP22 GP 32 Series Pump Manual

View
