• Finish Thompson Pump with motor GP11VVB01455C12

Image shown may not be actual product

Finish Thompson FTI

GP11VVB01455C12

0 reviews

Finish Thompson FTI Pump with motor GP11VVB01455C12 Sealed Non-Metallic Centrifugal, GP Series Plastic, 1 1/2" Suction, 1 1/2" Discharge, FKM O-Ring, PVDF, 35 psi, 126 GPM, GP11 Economical Chemical Handling

Item: GP11VVB01455C12
  • Overview
  • Series Info
  • Reviews
  • Literature/Manuals

GP11VVB01455C12

Finish Thompson FTI Pump with motor GP11VVB01455C12 Sealed Non-Metallic Centrifugal, GP Series Plastic, 1 1/2" Suction, 1 1/2" Discharge, FKM O-Ring, PVDF, 35 psi, 126 GPM, GP11 Economical Chemical Handling

Discharge NPT (Inches)1 1/2"
Heads To (Feet)82
HP2
Hz60
Impeller Size (Inches)4.50"
MaterialPVDF
Maximum Flow (GPM)126
Maximum Operating Temperature220°F (104°C)
Maximum Pressure (PSI)35 psi
Motor2hp/3450/3ph/60Hz/T/56C/230-460V
Motor Frame Size56C
Phase3
Pressure Rating BAR2.4 bar
Shaft Seal TypeBellows
Spec. Gravity1.8
Speed (RPM)3450
Suction NPT (Inches)1 1/2"
Valve/Seat/O-RingFKM
Voltage230-460

GP Sealed Plastic Centrifugal Pump Information

Features & Benefits
GP Sealed Plastic Centrifugal Pump Features:

• Mechanical seal horizontal centrifugal pump
• GF Polypropylene or CF PVDF corrosion resistant construction
• Accepts standards NEMA 56C, 145TC, 143-184JM, or IEC 80, 90, 100, and 112 motor frames
• Up to 7 1/2 Hp (3.0 kW) motors
• Back pull-out feature enables fast access for pump maintenance
• Close coupled or pedestal mounted
• Bellows, multi-spring or double seals
• Carbon, FKM or ceramic standard seal materials
• FKM or EPDM o-rings standard
• Up to 1.8 specific gravity with no impeller trimming
• Port sizes: 1.5” x 1.5”, 2” x 2”, 3” x 2”
• Maximum temperature: Polypropylene - 180oF (82oC), PVDF - 220oF (104oC)
• Maximum working pressure: 35 psi / 2.4 Bar (GP11), 55 psi / 3.8 Bar (GP22/32)
General Description
FTI GP Series Typical Applications:
• Chemical processing, spraying, transfer
• Plating recirculation/filtration, PCB etching/rinse
• Mild corrosive or low budget applications where periodic seal replacement is not an issue

Categories

0 Reviews

Add a Review

You need to sign in to add a review.

TypeTitleLink

GP Series Pump Brochure

View

GP Series Pump Curves

View

GP Series Pump Datasheet

View

GP11 Series Pump Manual

View

GP22 GP 32 Series Pump Manual

View
