Finish Thompson FTI Pump End GP11PVM01455C Sealed Non-Metallic Centrifugal, GP Series Plastic, 1 1/2" Suction, 1 1/2" Discharge, FKM O-Ring, Polypropylene, 35 psi, 126 GPM, GP11 Economical Chemical Handling
Finish Thompson FTI Pump End GP11PVM01455C Sealed Non-Metallic Centrifugal, GP Series Plastic, 1 1/2" Suction, 1 1/2" Discharge, FKM O-Ring, Polypropylene, 35 psi, 126 GPM, GP11 Economical Chemical Handling
Discharge NPT (Inches) | 1-1/2" |
Heads To (Feet) | 82 |
Impeller Size (Inches) | 4.5" (4 1/2") |
Material | Polypropylene (PPG) |
Maximum Flow (GPM) | 126 |
Maximum Operating Temperature | 180°F (82°C) |
Maximum Pressure (PSI) | 35 psi |
Motor Frame Size | 56C |
Pressure Rating BAR | 2.4 bar |
Shaft Seal Type | Multispring |
Spec. Gravity | 1.8 |
Suction NPT (Inches) | 1-1/2" |
Valve/Seat/O-Ring | FKM |
Features & Benefits |
---|
GP Sealed Plastic Centrifugal Pump Features: • Mechanical seal horizontal centrifugal pump • GF Polypropylene or CF PVDF corrosion resistant construction • Accepts standards NEMA 56C, 145TC, 143-184JM, or IEC 80, 90, 100, and 112 motor frames • Up to 7 1/2 Hp (3.0 kW) motors • Back pull-out feature enables fast access for pump maintenance • Close coupled or pedestal mounted • Bellows, multi-spring or double seals • Carbon, FKM or ceramic standard seal materials • FKM or EPDM o-rings standard • Up to 1.8 specific gravity with no impeller trimming • Port sizes: 1.5” x 1.5”, 2” x 2”, 3” x 2” • Maximum temperature: Polypropylene - 180oF (82oC), PVDF - 220oF (104oC) • Maximum working pressure: 35 psi / 2.4 Bar (GP11), 55 psi / 3.8 Bar (GP22/32) |
General Description |
FTI GP Series Typical Applications: • Chemical processing, spraying, transfer • Plating recirculation/filtration, PCB etching/rinse • Mild corrosive or low budget applications where periodic seal replacement is not an issue |
Chemical Delivery / Processing
22853 productsFiltration Systems
1862 productsManufacturing
20389 productsPlating
23448 productsRecirculation
78 productsSpray Systems
1862 productsProduct | qty. | shipping | price | ||
---|---|---|---|---|---|
M100101-1 | Ships in | $284.05 | |||
108173-1 | Ships in | $284.05 | |||
M100109-1 | Ships in | $167.20 | |||
M100112 | Ships in | $161.50 | |||
M101572-1 | Ships in | $244.15 | |||
J100109 | Ships in | $1,488.65 | |||
J100111 | Ships in | $9.51 | |||
J100112 | Ships in | $4.75 | |||
J100113 | Ships in | $0.09 | |||
J100114 | Ships in | $0.60 | |||
J100115 | Ships in | $0.16 | |||
J100116 | Ships in | $37.05 | |||
J100118 | Ships in | $21.85 | |||
J100120 | Ships in | $71.25 | |||
M100115 | Ships in | $9.51 | |||
A100856 | Ships in | $190.95 | |||
J100220 | Ships in | $0.43 | |||
A100185 | Ships in | $237.50 | |||
M101637-1 | Ships in | $60.80 | |||
M101637-2 | Ships in | $60.80 | |||
J100932 | Ships in | $0.14 | |||
J103312 | Ships in | $3.76 |
