Image shown may not be actual product
Finish Thompson DB5.5V-M615 Pump, FTI DB5.5 Magnetic Drive Centrifugal DB Series Sealless Pumps, 1/4 HP, 230 Volt, 50-60 HZ, 1 Phase, 1" Suction, 3/4" Discharge, FKM O-Ring, PVDF, 30 GPM, 60 PSI, 31 Feet of Head. To Order, See Complete Model Number DB5.5V-64-M615 Below in Related Items.
Finish Thompson DB5.5V-M615 Pump, FTI DB5.5 Magnetic Drive Centrifugal DB Series Sealless Pumps, 1/4 HP, 230 Volt, 50-60 HZ, 1 Phase, 1" Suction, 3/4" Discharge, FKM O-Ring, PVDF, 30 GPM, 60 PSI, 31 Feet of Head. To Order, See Complete Model Number DB5.5V-64-M615 Below in Related Items.
Bushing | Carbon |
Connection Type | NPT |
Discharge NPT (Inches) | 3/4" |
Heads To (Feet) | 31 |
HP | 0.25 |
Hz | 50/60 |
Impeller Size (Inches) | 3" |
Magnet | 6-pole |
Material | PVDF |
Maximum Flow (GPM) | 30 |
Maximum Operating Temperature | 220°F (104°C) |
Maximum Pressure (PSI) | 60 psi (413 kPa) |
Motor Frame Size | IEC 71 |
Phase | 1 |
Pressure Rating BAR | 4.1 bar |
Product Notes | See Correct Model DB5.5V-64-M615 Below to Order This Pump. |
Spec. Gravity | up to 1.8 |
Speed (RPM) | 2850/3450 |
Suction NPT (Inches) | 1" |
Valve/Seat/O-Ring | FKM |
Voltage | 230 |
Features & Benefits |
---|
DB Sealless Magnetic Drive Centrifugal Pumps Capabilities: + Five-year warranty + Extended run dry ability (with carbon bushing) + High operating efficiency + Polypropylene or PVDF construction + Powerful neodymium magnets + Close-coupled design + Threaded NPT or BSP connections + Horizontal or vertical installation + Back pullout design + Mounts to IEC 56, 63, 71 B14 motor frames + Easy set, measurement free drive + CE certified + Working pressure to 60 psi (4.1 bar) + Specific gravity up to 1.8 + Viscosity up to 50 cP + Polypropylene—180o F (82o C) + PVDF—220o F (104o C) |
General Description |
DB Series Pumping Applications: + Chemical processing + Plating + Water and wastewater + Electronics + Pharmaceuticals + Wet scrubber + Pulp and paper + Heat exchanger + and many more! |
Agriculture
5956 productsAquariums / Zoos
5956 productsChemical Delivery / Processing
22853 productsGeneral Purpose
5956 productsHeat Exchangers
6346 productsManufacturing
20389 productsMining
6084 productsPlating
23448 productsPulp & Paper
6474 productsSewage / Wastewater
20311 productsWater Treatment
7855 productsType | Title | Link | |
---|---|---|---|
DB, SP, MSDB Series Pumps Brochure (2022) | View | ||
Chemical Processing Applications Flyer (2022) | View | ||
DB5.5 Series Pumps Datasheet (2022) | View | ||
DB & SP Series Baseplates Datasheet (2022) | View | ||
DB, SP, UC, Series M20 Power Monitor Datasheet (2022) | View | ||
DB Series Pumps Performance Curves (2022) | View | ||
DB3 thru DB5.5 Series Pumps Installation & Operation Manual (2022) | View |
Product | qty. | shipping | price | ||
---|---|---|---|---|---|
A102865-7 | Ships in 3-5 Days | $108.30 | |||
J103572 | Ships in | $2.70 | |||
107122-19 | Ships in | Call for pricing | |||
M102141 | Ships in | $45.60 | |||
J102387 | Ships in | $150.10 | |||
106700-1 | Ships in | $129.20 | |||
107131-2 | Ships in | Call for pricing | |||
106309 | Ships in | $4.79 | |||
J102466 | Ships in | $0.62 | |||
107563-1 | Ships in | $33.25 | |||
J101020 | Ships in | $0.18 | |||
107570 | Ships in | $0.48 | |||
J101020 | Ships in | $0.18 | |||
106312 | Ships in | $0.28 | |||
106320 | Ships in | $0.04 | |||
106316 | Ships in | $1.82 | |||
107792 | Ships in | $0.54 |
