• Finish Thompson AV8SJS1V1C75018 AV8 Pump Series

Image shown may not be actual product

Finish Thompson FTI

AV8SJS1V1C75018

0 reviews

Finish Thompson Centrifugal Pump End AV8SJS1V1C75018, AV Series Stainless Steel Vertical Pump, FTI AV8, 2 x 1-1/2 NPT, FKM O-Ring, 7.50" Closed design impeller, 100 psi, 242 GPM

$5,190.40

Item: AV8SJS1V1C75018
  • Overview
  • Series Info
  • Reviews
  • Literature/Manuals

AV8SJS1V1C75018

Finish Thompson Centrifugal Pump End AV8SJS1V1C75018, AV Series Stainless Steel Vertical Pump, FTI AV8, 2 x 1-1/2 NPT, FKM O-Ring, 7.50" Closed design impeller, 100 psi, 242 GPM

Base Model NumberAV8
BushingCarbon
Column Length22"
Connections / Discharge (Inches)2 x 1-1/2 NPT
Discharge NPT (Inches)1 1/2"
Heads To (Feet)247
Impeller CodeStandard
Impeller Size (Inches)7.50"
Material316 SS
Maximum Flow (GPM)242
Maximum Operating Temperature300°F (149°C)
Maximum Pressure (PSI)100 PSI
Motor Frame SizeNEMA 184TC
Pressure Rating BAR6.9 bar
Spec. Gravityup to 1.8
Suction NPT (Inches)2"
Valve/Seat/O-RingFKM

AV Vertical Metallic Centrifugal Pumps Information

Features & Benefits
AV Series Typical Applications
• Chemical processing
• Plating, photo processing
• Printed circuit boards
• Pharmaceutical
• Waste water treatment

AV Vertical Metallic Centrifugal Pump Features:
• Corrosion resistant 316 stainless steel
• Close coupled
• Back pull out design for easy service
• Compact design with secure V-clamp (304 stainless steel)
• Standard, recessed, or high head impellers
• SS mounting plate for in-tank installation (AV models only)
• FKM, EPDM, or carbon lower bushings (AV models only)
• 1.8 specific gravity with no impeller trim
• Maximum temperature: 300°F (149°C)
• Maximum working pressure: 100 psi (6.9 bar)
General Description
AV Vertical Metallic Centrifugal Pumps are compact in design, easy to operate and handle, and economically priced. Built from high quality 316 stainless steel, these pumps are available in horizontal, vertical, or vertical cantilevered designs. All wetted parts are constructed of corrosion resistant materials to withstand the harshest chemical environments. The AP Series accept standard NEMA and IEC frame motors
and feature standard NPT or BSP threaded ports with tri-clamp or flanges optional.
