• Finish Thompson AV6HJS1V1C6205C13 AV6H Pump Series

Image shown may not be actual product

Finish Thompson FTI

AV6HJS1V1C6205C13

0 reviews

Finish Thompson AV6HJS1V1C6205C13, FTI AV Series Stainless Steel Vertical Pump, AV6H 1-1/4 x 3/4 NPT, Volt, 3450 RPM, FKM O-Ring, 3 Phase, 3 HP, 6.25" Closed design impeller, 60 Hz, 100 psi, 100 GPM

$6,280.00

Item: AV6HJS1V1C6205C13
  • Overview
  • Series Info
  • Reviews
  • Literature/Manuals

AV6HJS1V1C6205C13

Finish Thompson AV6HJS1V1C6205C13, FTI AV Series Stainless Steel Vertical Pump, AV6H 1-1/4 x 3/4 NPT, Volt, 3450 RPM, FKM O-Ring, 3 Phase, 3 HP, 6.25" Closed design impeller, 60 Hz, 100 psi, 100 GPM

Base Model NumberAV6H
BushingCarbon
Column Length22"
Connections / Discharge (Inches)1-1/4 x 3/4 NPT
Discharge NPT (Inches)3/4"
Heads To (Feet)144
HP3
Hz60
Impeller CodeHigh Head
Impeller Size (Inches)6.25"
Material316 SS
Maximum Flow (GPM)100
Maximum Operating Temperature300°F (149°C)
Maximum Pressure (PSI)100 PSI
Motor3hp/3450/3ph/60Hz/H/182TC/230-460V
Motor Frame SizeNEMA 56C
Phase3
Pressure Rating BAR6.9 bar
Spec. Gravityup to 1.8
Speed (RPM)3450
Suction NPT (Inches)1 1/4"
Valve/Seat/O-RingFKM

AV Vertical Metallic Centrifugal Pumps Information

Features & Benefits
AV Series Typical Applications
• Chemical processing
• Plating, photo processing
• Printed circuit boards
• Pharmaceutical
• Waste water treatment

AV Vertical Metallic Centrifugal Pump Features:
• Corrosion resistant 316 stainless steel
• Close coupled
• Back pull out design for easy service
• Compact design with secure V-clamp (304 stainless steel)
• Standard, recessed, or high head impellers
• SS mounting plate for in-tank installation (AV models only)
• FKM, EPDM, or carbon lower bushings (AV models only)
• 1.8 specific gravity with no impeller trim
• Maximum temperature: 300°F (149°C)
• Maximum working pressure: 100 psi (6.9 bar)
General Description
AV Vertical Metallic Centrifugal Pumps are compact in design, easy to operate and handle, and economically priced. Built from high quality 316 stainless steel, these pumps are available in horizontal, vertical, or vertical cantilevered designs. All wetted parts are constructed of corrosion resistant materials to withstand the harshest chemical environments. The AP Series accept standard NEMA and IEC frame motors
and feature standard NPT or BSP threaded ports with tri-clamp or flanges optional.
