• Finish Thompson AV4STS1V1C3505J02 AV4 Pump Series

Image shown may not be actual product

Finish Thompson FTI

AV4STS1V1C3505J02

0 reviews

Finish Thompson AV4STS1V1C3505J02, FTI AV Series Stainless Steel Vertical Pump, AV4 3/4" x 1/2" NPT/BSP, 115-230 Volt, 3450 RPM, FKM O-Ring, 1 Phase, 1/2 HP, 3.50" Closed design impeller, 60 Hz, 100 psi, 39 GPM

$1,716.00

Item: AV4STS1V1C3505J02
  • Overview
  • Series Info
  • Reviews
  • Literature/Manuals

AV4STS1V1C3505J02

Finish Thompson AV4STS1V1C3505J02, FTI AV Series Stainless Steel Vertical Pump, AV4 3/4" x 1/2" NPT/BSP, 115-230 Volt, 3450 RPM, FKM O-Ring, 1 Phase, 1/2 HP, 3.50" Closed design impeller, 60 Hz, 100 psi, 39 GPM

Base Model NumberAV4
BushingCarbon
Column Length12"
Connections / Discharge (Inches)3/4" x 1/2" NPT/BSP
Discharge NPT (Inches)1/2"
Heads To (Feet)59
HP1/2
Hz60
Impeller CodeStandard
Impeller Size (Inches)3.50"
Material316 SS
Maximum Flow (GPM)39
Maximum Operating Temperature300°F (149°C)
Maximum Pressure (PSI)100 PSI
Motor1/2hp/3450/1ph/60Hz/T/56J/115-230V
Motor Frame SizeNEMA 56J
Phase1
Pressure Rating BAR6.9 bar
Spec. Gravityup to 1.8
Speed (RPM)3450
Suction NPT (Inches)3/4"
Valve/Seat/O-RingFKM
Voltage115-230

AV Vertical Metallic Centrifugal Pumps Information

Features & Benefits
AV Series Typical Applications
• Chemical processing
• Plating, photo processing
• Printed circuit boards
• Pharmaceutical
• Waste water treatment

AV Vertical Metallic Centrifugal Pump Features:
• Corrosion resistant 316 stainless steel
• Close coupled
• Back pull out design for easy service
• Compact design with secure V-clamp (304 stainless steel)
• Standard, recessed, or high head impellers
• SS mounting plate for in-tank installation (AV models only)
• FKM, EPDM, or carbon lower bushings (AV models only)
• 1.8 specific gravity with no impeller trim
• Maximum temperature: 300°F (149°C)
• Maximum working pressure: 100 psi (6.9 bar)
General Description
AV Vertical Metallic Centrifugal Pumps are compact in design, easy to operate and handle, and economically priced. Built from high quality 316 stainless steel, these pumps are available in horizontal, vertical, or vertical cantilevered designs. All wetted parts are constructed of corrosion resistant materials to withstand the harshest chemical environments. The AP Series accept standard NEMA and IEC frame motors
and feature standard NPT or BSP threaded ports with tri-clamp or flanges optional.
