Finish Thompson AK5STS1V14005J09, FTI AK5 Vertical Sealed Stainless Steel Cantilevered Centrifugal Pump, 1-1/2" x 1-1/4" NPT, 115-230 Volt, 3450 RPM, FKM O-Ring, 1 Phase, 1 HP, 4.00" Closed design impeller, 60 Hz, 100 psi, 122 GPM
Finish Thompson AK5STS1V14005J09, FTI AK5 Vertical Sealed Stainless Steel Cantilevered Centrifugal Pump, 1-1/2" x 1-1/4" NPT, 115-230 Volt, 3450 RPM, FKM O-Ring, 1 Phase, 1 HP, 4.00" Closed design impeller, 60 Hz, 100 psi, 122 GPM
Base Model Number | AK5 |
Column Length | 12" |
Connections / Discharge (Inches) | 1-1/2" x 1-1/4" NPT |
Discharge NPT (Inches) | 1-1/4" |
Heads To (Feet) | 85 |
HP | 1 |
Hz | 60 |
Impeller Code | Standard |
Impeller Size (Inches) | 4" |
Material | 316 Stainless Steel |
Maximum Flow (GPM) | 122 |
Maximum Operating Temperature | 300°F (149°C) |
Maximum Pressure (PSI) | 100 psi (6.9 Bar) |
Motor | 1hp/3450/1ph/60Hz/T/56J/115-230V |
Motor Frame Size | NEMA 56J |
Phase | 1 |
Pressure Rating BAR | 6.9 bar |
Spec. Gravity | up to 1.8 |
Speed (RPM) | 3450 |
Suction NPT (Inches) | 1-1/2" |
Valve/Seat/O-Ring | FKM |
Voltage | 115/230 |
Features & Benefits |
---|
AK Series Typical Applications include: Pharmaceutical, Waste water & water treatment, Chemical transfer |
General Description |
Finish Thompson FTI AV Series are rugged, metallic centrifugal pumps are compact in design, easy to operate and handle, and economically priced. Built from high quality 316 stainless steel, these pumps are available in horizontal, vertical, or vertical cantilevered designs. All wetted parts are constructed of corrosion resistant materials to withstand the harshest chemical environments. The AP Series accept standard NEMA and IEC frame motors and feature standard NPT or BSP threaded ports with tri-clamp or flanges optional. |
Chemical Delivery / Processing
22853 productsManufacturing
20389 productsPharmaceutical / Chemical
15972 productsPlating
23448 productsSewage / Wastewater
20311 productsProduct | qty. | shipping | price | ||
---|---|---|---|---|---|
A102134-2 | Ships in | $259.35 | |||
M100115 | Ships in | $9.51 | |||
J100128 | Ships in | $0.11 | |||
J100115 | Ships in | $0.16 | |||
J103118 | Ships in | $0.58 | |||
J104219 | Ships in | $4.00 | |||
A102177 | Ships in | $827.45 | |||
M101896-1 | Ships in | $282.15 | |||
J102960 | Ships in 3-5 Days | $7.12 | |||
J102947 | Ships in 1 Week | $81.70 | |||
A102114-4 | Ships in | $339.15 | |||
J101293 | Ships in | $0.08 | |||
J102282 | Ships in | $0.10 | |||
J103196 | Ships in | $5.52 | |||
A102112-1 | Ships in | $411.35 | |||
A102112-2 | Ships in | $367.65 | |||
J103049 | Ships in | $102.60 | |||
M101897-1 | Ships in | $98.80 |
