Finish Thompson Centrifugal Pump End AK4STS1V13505J, Vertical Sealed Stainless Steel Cantilevered FTI AK4, 3/4" x 1/2" NPT/BSP, FKM O-Ring, 3.50" Open design impeller, 100 psi, 39 GPM
|Base Model Number||AK4|
|Connections / Discharge (Inches)||3/4" x 1/2" NPT/BSP|
|Discharge NPT (Inches)||1/2"|
|Heads To (Feet)||59|
|Impeller Size (Inches)||3.50"|
|Maximum Flow (GPM)||39|
|Maximum Operating Temperature||300°F (149°C)|
|Maximum Pressure (PSI)||100 psi|
|Motor Frame Size||NEMA 56J|
|Pressure Rating BAR||6.9 bar|
|Spec. Gravity||up to 1.8|
|Suction NPT (Inches)||3/4"|
|Features & Benefits|
|AK Series Typical Applications include: Pharmaceutical, Waste water & water treatment, Chemical transfer|
|Finish Thompson FTI AV Series are rugged, metallic centrifugal pumps are compact in design, easy to operate and handle, and economically priced. Built from high quality 316 stainless steel, these pumps are available in horizontal, vertical, or vertical cantilevered designs. All wetted parts are constructed of corrosion resistant materials to withstand the harshest chemical environments. The AP Series accept standard NEMA and IEC frame motors and feature standard NPT or BSP threaded ports with tri-clamp or flanges optional.|
