201394

Image shown may not be actual product

201394

0 reviews

BJM Pumps 201394 RX Series Lightweight, Corrosion-Resistant Dewatering Pump, Model: RX15SS. 2 HP (Horsepower), 230V, 2 Pole, 60 Hz, 3 Phase (3 Ph), 3450 RPM Motor. Car/Cer/FKM & SilCar/SilCar/FKM Dual Mechanical Seal, 5.04" 316 Stainless Steel Impeller, with 2" NPT Male Discharge Connections. 116 GPM (Gallons Per Minute) Maximum Flow, Heads to 70 ft., 104°F Maximum Liquid Temperature, and 0.25" (1/4") Maximum Solids Handling. An Industrial Flow Solutions Brand Product.

$6,488.25

Best Price Guarantee!
1297PumpPoints

Ships within 1 business day (in-stock items). Delivery typically 1–5 business days.

Item: 201394 | Model #: RX15SS

Overview
Series Info
Reviews
Literature/Manuals
Repair Parts

201394

Build	316 Stainless Steel Volute
Built in Overload Protection	Thermal & Amp. Overload
Cable Length	50 ft. (15 m)
Connections / Discharge (Inches)	2" NPT Male
Connection Size	2"
Connection Type	NPT Male
Elastomer	FKM
Full Load Amp (FLA)	6
Heads To (Feet)	70 ft. (21.3 m)
HP	2 HP
Hz	60 Hz
Impeller Material	316 Stainless Steel
Impeller Size(Inches)	5.04" (128 mm)
Includes	Thermal Overload Protection
Insulation Class	F
Liquid Temperature	104°F (40°C)
Material	Cast 316 Stainless Steel

Maximum Flow (GPM)	116 GPM (439.1 LPM)
Model Number	RX15SS
Motor Housing Material	316 Stainless Steel
Motor Type	Submersible, Continuous Duty
Phase	3 Ph (Three Phase)
Pole	2 Pole
Service Factor	1.1
Shaft Seal Material	Carbon / Ceramic / FKM & Silicon Carbide / Silicon Carbide / FKM
Shaft Seal Type	Dual Mechanical Seal
Solids (Inches)	1/4" (6.35 mm)
Speed (RPM)	3450 RPM
Strainer Material	316 Stainless Steel
Type	Dewatering, Top Discharge
Valve / Seat / O-Ring	FKM O-Rings
Voltage	230V

RX Series Lightweight, Corrosion-Resistant Dewatering Pumps Information

Lightweight Stainless Steel Dewatering for Corrosive Environments

The BJM Pumps RX Series is designed for lightweight, corrosion-resistant dewatering using fully cast 316 stainless steel construction. These pumps are ideal for applications involving corrosive liquids, saltwater, washdown, and chemically aggressive environments where traditional cast iron pumps would fail.

With a compact design and top discharge configuration, the RX Series delivers reliable performance while maintaining portability and ease of use.

Built for Corrosion Resistance

RX Series pumps are constructed entirely from cast 316 stainless steel, including the motor housing, volute, and internal components. The cast construction eliminates welds, improving structural integrity and reducing corrosion risk at joints.

Standard FKM elastomers provide additional chemical resistance, with optional EPDM or Buna materials available to match specific application requirements.

Key Features & Benefits

Full 316 stainless steel construction for corrosion resistance
Cast construction with no welds for increased durability
Lightweight, portable design
Top discharge configuration for motor cooling
Mechanical seal system for reliable operation
FKM elastomers standard (optional EPDM or Buna)
Built-in thermal overload protection
Class F motor insulation
Three-phase models suitable for VFD operation
Continuous duty rated

Designed for Corrosive Dewatering

The RX Series is optimized for clean water and lightly contaminated corrosive fluids with limited solids. These pumps provide a direct stainless steel alternative to standard dewatering pumps where corrosion resistance is critical for long-term reliability.

Performance Specifications

Horsepower (HP): 1 HP – 2 HP

Max Flow: Up to ~117 GPM

Max Head: Up to ~70 ft

Max Solids Handling: Up to ~1/4"

Motor Speed: ~3450 RPM

Max Liquid Temperature: ~104°F (40°C)

Motor Insulation: Class F

Typical Services & Ideal Applications

Corrosive liquid dewatering
Saltwater and marine pumping
Industrial washdown and drainage
Food and beverage cleaning areas
Chemical and petrochemical facilities
Wastewater with corrosive components
