JHF Series High Head / High Temperature Dewatering Pumps Information

Features & Benefits

The JHF Series is engineered for demanding applications requiring both high discharge pressure and resistance to elevated temperatures. Its ability to operate in liquids up to 200°F makes it suitable for industrial environments where heat and pressure are critical factors.

The series delivers strong hydraulic performance while maintaining durability and reliability, ensuring consistent operation in continuous-duty applications. The inclusion of Seal Minder® monitoring provides an additional layer of protection by helping detect seal failure early.

Construction and Operational Design

The JHF Series combines cast iron hydraulic components with a 304 stainless steel motor housing, providing durability, corrosion resistance, and long service life in harsh environments.

Each pump features a double mechanical seal system with an additional lip seal, creating multiple layers of protection against fluid ingress. The submersible motor operates at approximately 3450 RPM and is designed for continuous-duty service in high-temperature conditions.

Class R insulation supports operation in elevated temperatures, while built-in thermal switches embedded in the windings help prevent overheating and motor damage.

Design Characteristics

Temperature Capability: Designed for operation in liquids up to 200°F (93°C)

Hydraulic Performance: High-head design capable of producing up to approximately 145 ft of head

Discharge Configuration: Side discharge design allows efficient installation and compatibility with guide rail systems

Seal System: Double mechanical seal with additional lip seal provides enhanced protection in high-temperature environments

Materials of Construction: Cast iron hydraulic components with 304 stainless steel motor housing for durability

Motor Design: High-speed 2-pole motor (~3450 RPM) with Class R insulation for heat resistance

Protection Features: Seal Minder® moisture detection and thermal sensors provide reliable monitoring and protection

Technical Summary

Power Range: 2 HP to 10 HP

Flow Capacity: Up to ~300 GPM

Head Range: Up to ~145 feet

Solids Handling: Up to 3/8 inch

Temperature Capability: Up to 200°F (93°C)

Motor Speed: ~3450 RPM

Typical Services & Ideal Applications

The JHF Series is designed for high-temperature, high-head dewatering applications where both pressure and thermal resistance are required. These pumps are commonly used in industrial plants, heated process systems, boiler applications, and environments requiring removal of hot liquids under pressure.

Their ability to combine high-head capability with high-temperature durability makes them an ideal solution for demanding applications requiring continuous operation, reliability, and long service life.
