141460

Image shown may not be actual product

141460

0 reviews

Barnes Submersible Grinder Recessed Vortex SGVF Pump Package. 1-1/4" NPT, Vertical, Bolt-on Flange Discharge with a Carbon / Ceramic / Buna-N Tandem Mechanical, Oil filled reservoir Seal. 2 HP, 240 Volts, 1 Ph (Single Phase) Motor. 12 Vane Vortex Cast Iron Impeller Design capable of handling Liquids at 160°F (71°C). Built with a 30 ft. (9.1 m) Cord Entry. A Crane Pumps & Systems Product.

$7,393.45

Best Price Guarantee!
1478PumpPoints

Ships within 1 business day (in-stock items). Delivery typically 1–5 business days.

Item: 141460 | Part #: 141460

Overview
Series Info
Reviews
Literature/Manuals
Repair Parts

141460

Discharge NPT (Inches)	1-1/4" NPT, Vertical, Bolt-on Flange
Elastomer	Buna-N
HP	2 HP
Hz	60 Hz
Impeller Material	Cast Iron
Impeller Style	12 Vane Vortex, with pump out vanes on back side. Dynamically balanced, ISO G6.3
Includes	Includes overload protection in the motor.
Insulation Class	Class B
Liquid Temperature	160°F (71°C)
Motor	NEMA L-Single Phase, Oil Filled, Squirrel Cage Induction
Motor Housing Material	Cast Iron ASTM A-48, class 30
Motor Shaft Material	416 Stainless Steel
Part Number	141460

Phase	1 Ph (Single Phase)
Product Notes	Pump: SGVF2022L. Capacitor start/capacitor run, 24X84 Basin Package
Rotating Face	Carbon
Seal Plate Material	Cast Iron ASTM A-48, class 30
Shaft Seal Material	Carbon / Ceramic / Buna-N
Shaft Seal Type	Tandem Mechanical, Oil filled reservoir
Speed (RPM)	3450 RPM
Stationary	Ceramic
Valve / Seat / O-Ring	Buna-N Square Ring
Voltage	240 Volts
Volute Case Material	Cast Iron ASTM A-48, class 30

SGV Series Information

Features & Benefits
SGV Pump Advantages • Recessed vortex impeller design virtually eliminates pump damage from cavitation • Unique and robust 3-bearing shaft support design significantly extends mechanical seal life by minimizing shaft deflection • Cast iron impeller will not corrode • Exclusive Slicerator grinder eliminates jams • Quick-connect power cord eliminates wiring mistakes • Available from factory with pre-wired and tested basin package • Available in 2 hp, 3 hp, 5 hp, and 7.5 hp models • Double mechanical seal provides clean environment for long life UltraGrind™ Systems Offer • Low initial costs • Extended MTBSC (Mean Time between Service Calls) • Low life-cycle costs • Installation ease • Trouble-free operation High Capacity To 200 (duplex) gpm; heads to 160 ft TDH Installation and Start-Up Assistance Barnes’ maintenance experts can provide on site training and assistance to make sure installation is correct, efficient and easily repeatable.
General Description
Exclusive Slicerator™ The staggered slicing action of the radial grinder cutter dramatically reduces the torque requirement of the motor, cuts with less horsepower, and increases the unit’s efficiency. This helps prevent clogging with particularly troublesome objects such as plastic, rubber, sanitary napkins, disposable diapers and cloth items. UltraCAP II™ Removable Dry Well Optional rotomolded polyethylene removable dry well with integrated control panel eliminates the need to connect any wires inside the pump station. Flexible Connector Prevents potential misalignment problems by compensating for different settling rates of basin and discharge pipe. Level Control Systems Options including modularized control assemblies are available including mechanical floats and the ESPS™ (Environmentally Sealed Pressure Switch). Stealth™ Control Panels UL Listed, family of Stealth control panels provides cost effective and reliable pump station operation along with potential malfunction warning.

0 Reviews

Add a Review

You need to sign in to add a review.

Type	Title		Link
	Barnes Pump SGV Series Brochure		View
	Barnes Pump SGV Series 2 HP Manual		View
	Barnes Pump SGV Series 3,5, 7.5 HP Manual		View
	Barnes Pump SGV Series 3, 5, 7.7 HP Specifications		View
	Barnes Pump SGV Series 2 HP Specifications		View
