Barnes Submersible Grinder Recessed Vortex OGVF Pump. 1-1/4" NPT, Vertical, bolt-on flange Discharge with a Silicon-carbide / Silicon-carbide / Buna-N Single Mechanical Seal. 2 HP, 240 Volts, 1 Ph (Single Phase) Motor. 12 Vane Vortex Cast Iron Impeller Design capable of handling Liquids at 160°F (71°C). Built with a 30 ft. (9.1 m) Cord Entry. A Crane Pumps & Systems Product.

$4,693.35

Best Price Guarantee!
938PumpPoints

Ships within 1 business day (in-stock items). Delivery typically 1–5 business days.

Item: 130724 | Part #: OGVH2022CE

Overview
Series Info
Reviews
Literature/Manuals
Repair Parts

130724

Discharge NPT (Inches)	1-1/4" NPT, Vertical, bolt-on flange
Elastomer	Buna-N
HP	2 HP
Hz	60 Hz
Impeller Material	Cast Iron
Impeller Style	12 Vane Vortex, with pump out vanes on back side. Dynamically balanced, ISO G6.3
Insulation Class	Class F
Liquid Temperature	160°F (71°C)
Motor	NEMA L-Single Phase Torque Curve, Oil-Filled, Squirrel Cage Induction
Motor Housing Material	Cast Iron ASTM A-48, class 30
Motor Shaft Material	416 Stainless Steel
Part Number	OGVH2022CE

Phase	1 Ph (Single Phase)
Rotating Face	Silicon-carbide
Seal Plate Material	Cast Iron ASTM A-48, class 30
Shaft Seal Material	Silicon-carbide / Silicon-carbide / Buna-N
Shaft Seal Type	Single Mechanical
Speed (RPM)	3450 RPM
Stationary	Silicon-carbide
Valve / Seat / O-Ring	Buna-N Square Ring
Voltage	240 Volts
Volute Case Material	Cast Iron ASTM A-48, class 30

OGV Series Information

Features & Benefits
Reduced Life-cycle Costs • Heavy-duty 2 hp motor with oil lubricated upper and lower ball bearing standard for minimal wear • Heavy-duty industrial silicon carbide seal for extended usage • Large pump end bearing and short shaft overhang signifi cantly extends mechanical seal life by reducing shaft defl ection • Reliable Solid Start Switch provides longer life-cycle and improves mean time between service calls • Oil-filled motor enables the pump motor to run cooler under severe operating conditions Higher Flow Version: Capacities to 55 GPM, Heads to 104 Feet Higher Head Version: Capacities to 33 GPM, Heads to 125 Feet Accessory Options: • Pump Support Stand • Break Away Fitting or moveable slide rail fitting • ESPS™ (Environmentally Sealed Pressure Switch) Level Controls Omni Grind Features 1. Quick disconnect cord 2. Threaded discharge " ange 3. Exclusive Slicerator 4. Integral capacitors for start and run 5. Oil # lled motor with overload protection 6. Silicon carbide mechanical seal for long life 7. Vortex impeller for solids handling
General Description
Exclusive Slicerator™ The staggered slicing action of the grinder radial cutter dramatically increases the torque at the cutting surface, cuts with less horsepower, and increases the unit’s efficiency. Eliminates clogging with particularly troublesome objects such as plastic, rubber, sanitary napkins, disposable diapers and cloth items.

0 Reviews

Add a Review

You need to sign in to add a review.

Type	Title		Link
	Barnes Pump OGV Omni Grind Series Brochure		View
	Barnes Pump OGV Series Manual		View
	Barnes Pump OGV Omni Grind Series Specifications		View
	Barnes Pump OGVF-AU & OGVH-AU Series Specifications		View
	Barnes Pump OGVF2022M Series Specifications		View

Repair Parts for 130724

	shipping	price
108344	Lead Time TBD	$150.41	Select item
108343	Lead Time TBD	$29.37	Select item
108342	Lead Time TBD	$292.81	Select item
082085B	Lead Time TBD	$626.56	Select item
067556	Lead Time TBD	$35.60	Select item
070704	Lead Time TBD	$5.34	Select item
108369	Ships in 1-2 Weeks	$13.35	Select item
082088	Lead Time TBD	$1,015.49	Select item
109026	Ships in	$780.53	Select item
625-01558	Lead Time TBD	$5.34	Select item
1-131-1	Lead Time TBD	$5.34	Select item
067564	Lead Time TBD	$14.24	Select item
026322	Ships in	$5.34	Select item
062941	Lead Time TBD	$5.34	Select item
110395SD	Lead Time TBD	$258.99	Select item
016079	Lead Time TBD	$5.34	Select item
029034	Ships in	Call for pricing
095368	Lead Time TBD	$5.34	Select item
1-300-1	Lead Time TBD	$5.34	Select item
061143	Lead Time TBD	$5.34	Select item
Q10-36-E4	Ships in	$81.88	Select item
113287	Lead Time TBD	$193.13	Select item
108368A	Lead Time TBD	$1,132.08	Select item
115327A-RC	Ships in	$104.13	Select item
115327A-SC	Ships in	$120.15	Select item
105111B	Lead Time TBD	$5.34	Select item
016660	Ships in	$5.34	Select item
39462	Ships in	$250.68	Select item
103760-WAL	Ships in 5-7 Days	$106.00	Select item
2-31051-224	Ships in 2 Weeks	$5.34	Select item
1-156-1	Ships in	$5.34	Select item
109498XC	Lead Time TBD	$369.35	Select item
103582	Ships in 5-7 Days	$75.00	Select item
014270	Lead Time TBD	$5.34	Select item
110660-FTI	Ships in	Call for pricing
111328	Lead Time TBD	$5.34	Select item
105197	Lead Time TBD	$5.34	Select item
625-02117	Ships in	$5.34	Select item
108303	Lead Time TBD	$443.22	Select item
108330A	Ships in	$320.40	Select item
