104936A

Image shown may not be actual product

104936A

0 reviews

Barnes Sewage Ejector, 2SEV DS & L Vortex Double Seal Pump. 2" NPT, Female, vertical, bolt-on-flange Discharge with a Carbon / Ceramic / Buna-N Single Mechanical Seal. 1 HP, 240 Volts, 1 Ph (Single Phase) Motor. Open Vortex Cast Iron Impeller Design capable of handling Liquids at 104°F (40°C). Built with a 20 ft. Cord Entry. A Crane Pumps & Systems Product.

$1,946.35

Best Price Guarantee!
389PumpPoints

Ships within 1 business day (in-stock items). Delivery typically 1–5 business days.

Item: 104936A | Part #: 2SEV1024L 104936A

Overview
Series Info
Reviews
Literature/Manuals
Repair Parts

104936A

Discharge NPT (Inches)	2" NPT, Female, vertical, bolt-on-flange
Elastomer	Buna-N
HP	1 HP
Hz	60 Hz
Impeller Material	Cast Iron ASTM A-48, class 30
Impeller Style	Vortex, Open with Pump out vanes on Back side. Dynamically balanced, ISO G6.3
Insulation Class	Class B
Liquid Temperature	104°F (40°C)
Motor	NEMA L -single phase
Motor Housing Material	Cast Iron ASTM A-48, class 30
Motor Shaft Material	416 Stainless Steel

Options	Seal Material, Impeller Trims, Additional Cord, N/C Temperature Sensors with cord for 3 Phase pumps (Requires relay in Control Panel). N/O Moisture Sensor with cord for DS pumps (Requires relay in Control Panel), 3" NPT Discharge Adapter
Part Number	2SEV1024L 104936A
Phase	1 Ph (Single Phase)
Seal Plate Material	Cast Iron ASTM A-48, class 30
Shaft Seal Material	Carbon / Ceramic / Buna-N
Shaft Seal Type	Single Mechanical
Speed (RPM)	1750 RPM
Valve / Seat / O-Ring	Buna-N Square Ring
Voltage	240 Volts
Volute Case Material	Cast Iron ASTM A-48, class 30

2SEV DS & L Series Information

Features & Benefits
Motor - 1/2hp, 3/4hp, 1hp RPM - 1750 / 3450 Electrical - 115v 1ph (1/2hp only), 230v 1ph & 3ph, 460v 3ph, 575v 3ph Cord Length - 20' Construction - Cast Iron Impeller - Cast Iron Vortex Discharge - 2" Solids - 2" Automatic Operation (manual available) - No

0 Reviews

Add a Review

You need to sign in to add a review.

Type	Title		Link
	Barnes Pump Series 2SEV DS & L Manual		View
	Barnes Pump Series 2SEV DS 1/2 & 3/4 HP Specifications		View
	Barnes Pump Series 2SEV DS 1 1/2 & 2 HP Specifications		View
	Barnes Pump Series 2SEV L 1/2 & 3/4 HP Specifications		View
	Barnes Pump Series 2SEV L 1 1/2 & 2 HP Specifications		View
	2SEV-L & 3SEV-L Repair Parts: .5, .75 & 1.0 HP, 1750 & 3450 RPM		View

Repair Parts for 104936A

Product		shipping	price
55400			Call for Shipping
	69140	Lead Time TBD	Call for pricing
26210			Call for Shipping
	003217	Lead Time TBD	$5.34	Select item
	084532	Lead Time TBD	$548.24	Select item
	108342A	Ships in	$254.54	Select item
	029792BS	Ships in 1-2 Weeks	$1,174.80	Select item
	029034	Ships in	Call for pricing
	034964	Lead Time TBD	$175.33	Select item
	039858	Lead Time TBD	$13.35	Select item
	1-156-1	Ships in	$5.34	Select item
	026322	Ships in	$5.34	Select item
	105197	Lead Time TBD	$5.34	Select item
	2-31051-224	Ships in 2 Weeks	$5.34	Select item
	103584	Lead Time TBD	$40.05	Select item
	105111	Lead Time TBD	$5.34	Select item
	016660	Ships in	$5.34	Select item
	085326-BUR	Lead Time TBD	$5.34	Select item
	017414	Lead Time TBD	$40.05	Select item
	1-158-1	Lead Time TBD	$5.34	Select item
	027269	Lead Time TBD	$15.13	Select item
	005080	Lead Time TBD	$135.28	Select item
	105145-FTI	Ships in	Call for pricing
	105152TB-KIT	Ships in	$320.40	Select item
	014270	Lead Time TBD	$5.34	Select item
	1-36-1	Lead Time TBD	$5.34	Select item
	082727	Lead Time TBD	$5.34	Select item
	003217	Lead Time TBD	$5.34	Select item
	5-32-6-DEM	Ships in	$5.34	Select item
	052563	Lead Time TBD	$5.34	Select item
	084948	Lead Time TBD	$5.34	Select item
	051621	Lead Time TBD	$137.06	Select item
	105155-FTI	Ships in	$2,565.95	Select item
	134013	Ships in	$5.34	Select item
	105106	Lead Time TBD	$5.34	Select item
	103584	Lead Time TBD	$40.05	Select item
	103582	Ships in 5-7 Days	$75.00	Select item
	030337	Ships in	$5.34	Select item
	625-02117	Ships in	$5.34	Select item
	030068	Lead Time TBD	$5.34	Select item
	111909	Ships in	$4.45	Select item
	130207	Ships in 1-2 Weeks	$323.07	Select item
	107271-NEP	Ships in	$65.00	Select item
	085343	Lead Time TBD	$477.04	Select item
