62040202
Barmesa Pumps 62040202 Self-Priming Solids Handling Frame Mounted Pump, Model# SH4-U. 4" Suction, 4" Discharge 125# Flange Connections. Cast Iron Casing, Bearing Housing & Seal Plate, Neoprene Flap Valve. Ductile Iron 2 Vane, Open Impeller, Silicon Carbide / Silicon Carbide / Fluorocarbon Type 21 Mechanical, Oil Lubricated Double Floating, Self Aligning. Seal
$6,190.80
- Best Price Guarantee!
- 1237PumpPoints
Ships within 1 business day (in-stock items). Delivery typically 1–5 business days.
- Overview
- Reviews
- Literature/Manuals
62040202
Barmesa Pumps 62040202 Self-Priming Solids Handling Frame Mounted Pump, Model# SH4-U. 4" Suction, 4" Discharge 125# Flange Connections. Cast Iron Casing, Bearing Housing & Seal Plate, Neoprene Flap Valve. Ductile Iron 2 Vane, Open Impeller, Silicon Carbide / Silicon Carbide / Fluorocarbon Type 21 Mechanical, Oil Lubricated Double Floating, Self Aligning. Seal
| Bearing Housing | Cast Iron |
| Casing Material | Cast Iron |
| Connection Type | 125# Flange |
| Discharge NPT (Inches) | 4" |
| Impeller Material | Ductile Iron |
| Impeller Style | 2 Vane, Open |
| Model Number | SH4-U |
| Model Series | Self-Priming Solids Handling |
| Product Notes | Solids handling self-priming pump |
| Seal Plate Material | Cast Iron |
| Shaft Seal Material | Silicon Carbide / Silicon Carbide / Fluorocarbon |
| Shaft Seal Type | Type 21 Mechanical, Oil Lubricated Double Floating, Self Aligning. |
| Shaft Sleeve Material | 316 Stainless Steel |
| Size | 4" |
| Solids (Inches) | 3" |
| Suction NPT (Inches) | 4" |
| Type | Frame Mounted |
| Valve / Seat / O-Ring | Buna-N |
| Valve Type | Neoprene Flap Valve |
