Image shown may not be actual product
AOM3611T Baldor 3 AIR OVER HP, 1750 RPM, 3 PH, 60 HZ, 182T, 3622M, AC Motor, HVAC, Yoke/Pedestal Fan Motors, SPEC 36G256S914G1, UPC 781568121764
AOM3611T Baldor 3 AIR OVER HP, 1750 RPM, 3 PH, 60 HZ, 182T, 3622M, AC Motor, HVAC, Yoke/Pedestal Fan Motors, SPEC 36G256S914G1, UPC 781568121764
Frame Material | Steel |
HP | 3 |
Hz | 60.0 |
Insulation Class | B |
Manufacturer | Baldor-Reliance |
Motor Enclosure Type | TEAO - Totally Enclosed Air Over |
Motor Frame Size | 182T |
Motor Type | 3622M |
Phase | 3 |
Pole | 4 |
Quick Specs | 3 AIR OVERHP,1750RPM,3PH,60HZ,182T,3622M |
Service Factor | 1.15 |
SPEC | 36G256S914G1 |
Speed (RPM) | 1800 |
UPC | 781568121764 |
Voltage | 208/230/460 |
Type | Title | Link | |
---|---|---|---|
AOM3611T Datasheet | View |
