Image shown may not be actual product
AOM3546T Baldor 1 HP, 1725 RPM, 3 PH, 60 HZ, 143T, 3428M, TEAO, F1, AC Motor, HVAC, Yoke/Pedestal Fan Motors, SPEC 34T61-3254, UPC 781568121689
AOM3546T Baldor 1 HP, 1725 RPM, 3 PH, 60 HZ, 143T, 3428M, TEAO, F1, AC Motor, HVAC, Yoke/Pedestal Fan Motors, SPEC 34T61-3254, UPC 781568121689
Frame Material | Steel |
HP | 1 |
Hz | 60.0 |
Insulation Class | B |
Manufacturer | Baldor-Reliance |
Motor Enclosure Type | TEAO - Totally Enclosed Air Over |
Motor Frame Size | 143T |
Motor Type | 3428M |
Phase | 3 |
Pole | 4 |
Quick Specs | 1HP,1725RPM,3PH,60HZ,143T,3428M,TEAO,F1 |
Service Factor | 1.15 |
SPEC | 34T61-3254 |
Speed (RPM) | 1800 |
UPC | 781568121689 |
Voltage | 230V / 208V / 460V |
Type | Title | Link | |
---|---|---|---|
AOM3546T Datasheet | View |
