Burks 315GA4-3/4 Centrifugal Pump, Close Coupled, 60 Hz, Three Phase, 3500 RPM, 1 1/2 Horsepower, ODP Motor Enclosure, Frame Size 56J, 49 lbs.
Adapter Material
Cast Iron
Capacities (GPM)
130
Casing Material
Cast Iron
Casing Working Pressure
100
Discharge NPT (Inches)
3/4"
Heads To (Feet)
75
HP
1 1/2
Hz
60
Impeller Material
Bronze
Inlet Pressure (PSI)
70
Material
Bronze Fitted
Maximum Operating Temperature
225°F (107°C) - Standard Buna-N Seal
Motor Enclosure Type
ODP - Open Drip Proof
Motor Frame Size
56J
Motor Shaft Material
303 Stainless Steel
Phase
3 Ph (Three Phase)
Shaft Seal Material
Carbon / Ceramic / SS Buna-N
Speed (RPM)
3500
Suction NPT (Inches)
1
Voltage
208/230/460
GA4 Series Information
General Description
Burks GA4 Series - Centrifugal Pump, Close Coupled, End Suction
Materials of Construction
Adapter - All Iron: Cast Iron, Bronze Fitted: Cast Iron, All Bronze: Bronze. Casing - All Iron: Cast Iron, Bronze Fitted: Cast Iron, All Bronze: Bronze. Impeller - All Iron: Cast Iron, Bronze Fitted: Bronze, All Bronze: Bronze. Shaft: #303 Stainless Steel. Shaft Seal: Carbon Ceramic SS Buna-N
Motors
Standard pump motors are of open drip proof (ODP) construction and are rated with jet pump service factors for continuous duty operation. Motors are 56 frame size with NEMA standard mounting fl ange, one piece threaded stainless steel shaft and ball/ball bearing construction.
Four Position Casing
Discharge can be located in any of four positions. Casing is close grain iron of 30,000 psi minimum tensile strength. Back pull-out design eliminates the need to disturb piping should the pump ever require service - the casing stays in the line.
Enclosed Cast Iron Impeller
Of the latest hydraulic design for maximum efficiency, impeller is balanced for vibration-free operation and threaded onto stainless steel motor shaft. Impeller is available in bronze.
Mechanical Shaft Seal Information
Standard self-adjusting shaft seal for temperatures to 225°F (107°C) and pressures to 150 psi (1034 kpa). Ceramic seat and carbon seal face for long trouble-free service. Special seals are available for higher temperatures and fl uids other than water.
Factory Tested
After careful assembly and inspection, EVERY pump is factory tested and meets Hydraulic Institute standards.
Motor Information
60 Hz - 3450 RPM - ODP Single Phase: 1/3 thru 2 HP - 115/230 Volt, 3 HP - 230 Volt Only Three Phase: 1/3 thru 3 HP - 208-230/460 Volt 50 Hz - 2900 RPM - ODP Single Phase: 110/220 Volt Three Phase: 380 Volt
Overload Protection
All single phase ODP and Totally Enclosed motors have built-in overload protection. All three phase motors and all explosion proof motors must be installed with a magnetic starter which provides full 3-leg protection. Failure to use correct starter and overloads will void motor warranty.
